GMF400 Sewage water Insertion type electromagnetic flow meter

GMF400 Sewage water Insertion type electromagnetic flow meter

Category: Flow Meters >>>
Supplier: Xi'an,Gavin,Electronic,Technology,Co.,Ltd.

Price:

Price in USD:Details

Quantity:

Product Overview

Description

GMF400 Sewage water Insertion type electromagnetic flow meter

Description

_01

GMF400 Insertion electromagnetic flow meter is composed of insertion electromagnetic sensor and electromagnetic flow converter, used to measure the conductive liquid that electrical conductivity is greater than 5 us/cm , it is used to measure the water, sewage, acid, alkali and other medium. Suitable for measuring the large pipe of diameter DN300~DN3000mm,. Installation can be divided into a online installation type of the cut-off valve and water control installation type without stop valves.

Feature

♦ Simple structure, no moving parts, long service life.

♦ Don't need lining, don't need ground ring, small volume, light weight, convenient installation.

♦ Insertion electromagnetic flow meter with stop valves can realize the installation, dis-assembly, easy maintenance and maintenance when continuous streams.

♦ Flow measurement is only related to insert depth, so with the feature of wide commonality, strong interchangeability. A model can be applicable to all kinds of pipe flow measurement requirements.

Detail show

_03

Specification

GMF400 Insertion electromagnetic flow meter
Medium	Water, sewage water, acid, alkali etc.
Diameter	DN300~DN3000mm
Accuracy	±2.5%
Temp. range	-20~+150℃
Pressure	1.6 MPa
Flow rate	0.5~6m/s
Straight pipe required	Up stream≥5DN,down stream≥3DN
Electrode	316L,Hastelloy C(HC),Titanium(Ti),Tantalum(Ta),Platinum(Pt)
Installation way	Without a ball valve or with a ball valve
Body material	Stainless steel
Power supply	220VAC/24VDC/Lithium battery
Signal output	Pulse output,4~20mA
Communication	RS485,Hart, GPRS etc.
Explosion proof	No
Protection class	IP65(compact type), IP68(remote type)
Working environment	Temp. Range: -20~+60℃,humidity: 5%~90%

Flow rate Q=πD²×V×0.0036÷4

Type selection

GMF400

Application

Suitable for measuring the large pipe of diameter DN300~DN3000mm,. Installation can be divided into a online installation type of the cut-off valve and water control installation type without stop valves.

GMF400
