WCB 8inch 300LB two pcs Flange connection Ball valve according to ASTM
WCB 8inch 300LB two pcs Flange connection Ball valve according to ASTM

WCB 8inch 300LB two pcs Flange connection Ball valve according to ASTM

Share on (60646824027):


Price:

Quantity:


Product Overview

Description


Product Description
\t
Material of Construction:
\t
Cast Iron
\t
: IS 210 Gr FG 200
\t
Cast Carbon Steel
\t
: ASTM A 216 Gr WCB / WCC
\t
Cast Stainless Steel
\t
: ASTM A 351 Gr CF 8/CF 8M
\t
Forged Carbon Steel
\t
: ASTM A 105
\t
Forged Stainless Steel
\t
: ASTM A 182 Gr F304 / F316
\t
Design & Testing International Standard:
\t
Valve Design
\t
: API 594 / API 600(ISO 10434) / API 6D(ISO 14313) / API 602 / API 603 / API 608 /    API 609 / IS 780 / BS 1414 / BS 14846 / BS 1868 / BS 1873 / BS 5351 / ASME B 16.34(BS 5351) / DIN 3352 / DIN 3356 / DIN 3357
\t
Pressure Testing
\t
: API 598 / API 600 / API 6D
\t
Face To Face
\t
: ANSI B 16.10
\t
End Connection
\t
: Screwed AS PER BSP/BSPT/NPT, Weld AS PER SW/BW, Flange AS PER RF/RTJ
\t
Flange Connection
\t
: ANSI B 16.5 (For NPS≤24) / ANSI B 16.47 SERIES B, ANSI 16.47 SERIES A, MSS SP-44 (For NPS >24)
\t
Butt Weld End
\t
: ANSI B 16.25
\t
Socket Weld End
\t
: ANSI B 16.11
\t
Screwed End
\t
: ANSI B 1.20.1(BSP/NPT)
\t
Wall Thickness
\t
: API 600 / BS 1868
\t
Pressure Rating
\t
: AS PER ANSI 125#, 150#, 300#, 400#, 600#, 800#, 900#, 1500#, 2500#
\t
Engineering Option
\t
: Gear Operated, Electrical Actuated, Pneumatic Actuate
\t
Size Range
\t
: AS PER NPS 2" - 48"
Products Show

Construction of Ball Valve

Ball valves are manufactured in different body configurations and the most common are:
Top entry Ball valves allow access to valve internals for maintenance by removal of the valve Bonnet-cover. It is not required to be removed valve from the pipe system.
Split body Ball valves consists of a two parts, where one part is smaller as the other. The ball is inserted in the larger body part, and the smaller body part is assembled by a bolted connection.
The valve ends are available as butt welding, socket welding, flanged, threaded and others.

Advantages of Ball Valve


Quick quarter turn on-off operation
Tight sealing with low torque
Smaller in size than most other valves

Industrial Valves

China High Mpa Valve Manufacturing Co., Ltd. have main 5 production line include: Gate Valve, Globe Valve, Check Valve, Ball Valve, Butterfly Valve. Material include: Carbon Steel, Stainless Steel

Certifications
Workshop
China High Mpa Valve
Our Service

Over 15 years for design and produce valves.OEM & ODM Service. Provide you One Stop service and Door to Door delivery

Customer Photo
FAQ

Q: Are you trading company or manufacturer ?

A: We are factory.

Q: How long is your delivery time?

A: Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.

Q: Do you provide samples ? is it free or extra ?

A: Yes, we could offer the sample for free charge but do not pay the cost of freight.

Q: What is your terms of payment ?

A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
If you have another question, pls feel free to contact us as below:
