Mini mineral water plant complete mineral water bottling equipment

Features of  automatic mineral water production line

1. The machine concept of the CGF series was specifically designed for bottling in a hygienic environment;

2. Thanks to the free-standing transfer starwheels, there are much less exterior surfaces on the fillers than on conventional systems;

3. This innovative design has also the effect of the machine being very easily accessible for maintenance purposes and that it can be expanded at any time without conversion, for example with an additional cap feeder;

4. The OMRON / Siemens PLC system offers the ideal solution for conductive non-carbonated fill products, as the fill quantity is measured precisely by an inductive flow meter;

5. All filling process steps can be programmed easily and individually – adjusted to the product to be filled and to the container.

6. With all variants of the CGF series for non-carbonated products, the containers are conveyed through the machine by means of neck-handling. This, as well as fill quantity determination via inductive flow meter (IDM) guarantee high flexibility and short change-over times;



 Description
a. This water filling machine is mainly used for washing, filling and capping PET bottled non- carbonated drinks such as mineral water, pure water, stilled water, distilled water, etc.
b. Bottle washing, filling and capping are finished in one machine.
c. The contact time is shorten between material and the outside, avoid the second time pollution
d. CGF series filling machine adopts hanging type conveying-bottle structure to make changing bottle mold more convenient, faster .
e. The water filling machine adopts advanced PLC control technology. The main electric elements adopt Mitsubishi, Omron, Siemens, etc international famous products.

Operation
Ø  Empty bottles are fed manually onto the in feed Air conveyor.
Ø  From there bottles are carried to the Rinsing section.
Ø  Bottles gripped by neck & get tilted on rinsing nozzles.
Ø  Rinsed bottles are coming straight & get transferred to the filling section& are holded by neck.
Ø  Filled bottles are transferred to the capping section.
Ø  Capsare put in the rotaryhopper & tightened under the revolving capping heads, while coming out by out feed conveyor.

Filling Machine Equipment
Name	Quantity
1. Stainless Steel Washing Nozzles	8pcs
2. Stainless Steel Filling Nozzles	8pcs
3. Stainless Steel Capping Nozzles	3pcs
4. Empty Bottle Air Conveyor With Fan	2m for free
5. Filled Bottle Flat Conveyor With Motor	2m for free
6. Bottle Exchange Part For Different Bottle Size	3 sets for free
7. Stable Cap Loader	1set

THREE WORKING PARTS

	1.All 304 stainless steel rinser heads, water spray style inject design, more save water consumption & more clean 2.304 Stainless steel Gripper with plastic pad, ensure minimal bottle crash during washing 3.304 stainless steel washing pump
	1.304 Stainless steel high precision filling nozzle 2.Filling volume adjustable in fine rank, same liquid level after filling 3.All 304 stainless steel contact parts & liquid tank, fine polish, no death corner, easy to clean 4.304 stainless steel filling pump 5.no bottle no filling
	1.Place & capping system, electromagnetic capping heads, with burden discharge function, make sure minimum bottle crash during capping 2.All 304stainless steel construction 3.No bottle no capping, 4.Automatic stop when lack of bottle





Technical Data

Model	CGF8-8-3	CGF12-12-6	CGF18-18-6	CGF24-24-8	CGF32-32-8	CGF40-40-10	CGF50-50-12
Rinsing Head No	8	12	18	24	32	40	50
Filling Head No	8	12	18	24	32	40	50
Capping Head No	3	6	6	8	8	12/10	12/10
RatedCapacity (500ml)	2000BPH	4000BPH	7000-8000BPH	10000-12000BPH	12000-15000BPH	15000-18000BPH	20000-22000BPH
Overall Size	1900*14 20*2000mm	2200*16 00*2300mm	2450*19 00*2300mm	2750*21 80*2400mm	4000*23 00*2300mm	4550*26 50*2300mm	5450*32 10*2300mm
Weight	1.5T	2.2T	3.0T	4.0T	8.0T	12.0T	20.0T
Power(KW)	3.0kw	3.5kw	4.0kw	4.8kw	7.6kw	8.3Kw	9.6Kw
Rated Voltage	380V	380V	380V	380V	380V	380V	380V

Electrical components of filling machine

Name of part	Brand
AC Contactor	SIEMENS	GERMANY
Thermal overload relay
PLC
Touch Screen
Converter
Power Switch	SCHNEIDER	FRANCE
Intermediate Relay
Circuit Breaker	SIEMENS	GERMANY
Emergency	SCHNEIDER	FRANCE
Indicate Light
Potentiometer
Photoelectric switch	AUTONICS	KOREA
Access switch
Wiring terminals	Phoenix	GERMANY

RELIABLE Service
Reliable sample service
1.  Send you video of the running machine.
2.  Welcome to come to visit our factory, see the detail of machines.
3.  Well-trained & experienced staff are to answer all your inquiries in English and Chinese

Reliable Customized service
1.Design the machines according your requirements(material, voltage , filling type, various bottles, specially designed device and so on) .
2.Reliable Professional suggestion, as you know, our company is among the best in the beverage machinery industry and our engineer has experience for many years.
3.Design layout for you and offer you advice about machine orientation or based on the factory area you have.
Reliable After-sales service
1.  Deliver the machine and provide the B/L on time to make sure you can get the machine quickly. Also send operating manual and instruction.
2.  If you need, our professional engineer team will go to your factory to install the machine and train your employee until they can operate the machine well.
3.  Regular after-sales calling to remind customers to add the lubricating oil and maintain machine.
4.  Service office in Dubai and other countries and will also visit customers' factories to check the machines.
5.  The machines from Reliable Machinery has one year warranty for free and totally five years life-long technical support.
6.  24 hours for engineer response

If you have interests in our machine, just tell me some information:

1. How many bottles do you want to produce per hour?
2. What kind of bottle do you want to produce? And the type, height, volume of the bottle.
3. How much does the plant cover?
4. How much is the voltage of the plant?

 So, Any problem you have, please tell us without hesitation.
