Product Overview
Description
Product Description
Aluminum Foil Fiberglass Cloth High Quality Vacuum Insulation Panel
Item Name | Cooler insulation material | ||||
Thinckness | 10mm to 30mm,cuatomizable | ||||
Corel material | Fiberglass | ||||
Structure | Aluminum foil+glassfiber+aluminum foil | ||||
Size | Accept custom, Maximum size:100x160cm | ||||
Thermal conductivity | ≤0.0025W/mk | ||||
Compressive strength | ≥0.15MPa | ||||
Working temperature | -70 - 100℃ | ||||
Product description:
Vacuum Insulation Panel (VIP) is a kind of vacuum insulation material. The vacuum insulation panel is the world's advanced insulation material. The thermal conductivity is less than 0.0025w / mk. The vacuum insulation panel adopts the principle of vacuum insulation, The core materials can be chosen from from super-fine fibre, short-cut fibre . Outside, it is sealed with aluminium film or composite aluminium fiber.It effectively free from air convection caused by heat transfer, thermal conductivity significantly reduced, so as to achieve better insulation effect.
And It does not contain any ODS material, has the characteristics of environmental protection and high efficiency and energy saving, is currently the world's most advanced and efficient heat preservation material.
Applications:
Vacuum Insulation Panel can be widely use in household refrigerator, yacht refrigerator, mini refrigerator, car refrigerator, cryogenic freezer, electric water heater, vending machines, freezers, cold storage container, building wall thermal insulation and LNG storage and transportation, etc.
Cooler box with Glass fiber - VIP can keep box temperature 2C-8C for 48 to 72 hours,even for a longer time.
After several times of research and testing, Self-assembling insulation box have applied for our company's Patent. For Medical control temperature transport,Without affecting the effect of use, this design increases the flexibility of use and greatly reduced the transportation cost !
Detailed Images
Related Products
Medical/vaccine cooler box
External: 545x545x545mm
Internal: 435x435x425mm
After insert cold source: 380x380x350mm
Cold sourse : 39.7x19.7x2.5cm
Avalibale Capacity : 50L
Internal: 435x435x425mm
After insert cold source: 380x380x350mm
Cold sourse : 39.7x19.7x2.5cm
Avalibale Capacity : 50L
