2019 CE Application High Performance Industrial Water Cooled Chiller For Refrigeration Project
OUR Chillers are compact in size, low noise, great capacity, long life, high energy saving, high heat exchange efficiency and easy operation etc Features.
We also can be customized Chillers as customer's requirements ,before you ordering,please notice some questoins as below :
No.
Q
Remark
1
How much is the Cooling Capacity do you need ?
2
How much is Condensing Temperature ?(or tell us ambient temperature is also ok )
3
How much is Evaporation Temperature ?( or tell us room temperature is also ok)
4
Which refrigerant you will use ?
R404A/R134A Etc.
5
How much is your Power supply?
V/HZ/Phase
6
Which Brand Compressor do you like best ?
Bitzer/Dorin/Copeland Etc
7
Do you have any requirements for Components Brand?
Danfoss/Alco Etc.
THANK YOU!
Medium&Low Temperature Unit:
Model
Nominal cooling Capacity(W)
Compressor
Nominal power of compressor (HP)
Heat transfer area
Power supply
Fan Of Condenser
Liquid Receiver
Suction mm
Outlet mm
QTY
DIA mm
Air Flow m3/h
LK-AV08L/60
15250
4TCS-8.2
8
60
380V 50HZ 3PH
1
500
7000
8
35
16
LK-AV10L/80
17700
4PCS-10.2
10
80
1
600
10000
10
35
16
LK-AV12L/100
20850
4NCS-12.2
12
100
2
450
10000
12
35
16
LK-AV15L/120
26800
4H-15.2
15
120
2
500
14000
15
42
16
LK-AV20L/160
30950
4G0.2
20
160
2
600
20000
20
54
19
LK-AV25L/200
40250
6H5.2
25
200
3
600
20000
25
54
22
LK-AV30L/240
46500
6G-30.2
30
240
3
500
21000
35
54
22
LK-AV40L/300
55600
6F-40.2
40
300
3
600
30000
45
54
25
Note:1.Nominal cooling capacity means it's at the condition of R22,condensing temperature is 50℃,evaporation temperature is -15℃.
2.When evaporation temperature is below 0℃,should consider to use additional cooling or limit aspiratory temperature, maximum aspiratory overheating is 20K.
Medium&High temperature unit:
Model
Nominal cooling Capacity(W)
Compresser
Nominal power of compressor (HP)
Heat transfer area
Power supply
Fan of condenser
Liquid Receiver
Suction mm
Outlet mm
QTY
DIA mm
Air Flow m3/h
LK-AV06H/60
11850
4EC-6.2
6
60
380V 50HZ 3PH
1
500
7000
6
28
12
LK-AV09H/80
17500
4CC-9.2
9
80
1
600
10000
10
28
16
LK-AV10H/100
19200
4VCS-10.2
10
100
2
450
10000
10
28
16
LK-AV12H/120
23150
4TCS-12.2
12
120
2
500
14000
12
35
16
LK-AV15H/160
27700
4PCS-15.2
15
160
2
600
20000
15
42
16
LK-AV20H/200
32150
4NCS0.2
20
200
2
600
20000
20
42
22
LK-AV25H/240
41950
4H5.2
25
240
3
500
21000
25
54
22
LK-AV30H/270
48100
4G-30.2
30
270
3
550
25500
30
54
22
LK-AV35H/300
63000
6H35.2
35
300
3
600
30000
35
54
22
Unit Dimensions:
UNIT MODEL
A
B
C
D
E
F
Installing hole
LK-AV08L/60
1050
750
700
850
1380
1480
4-Φ13
LK-AV06H/60
LK-AV10L/80
1150
880
830
950
1500
1600
4-Φ13
LK-AV09H/80
LK-AV12L/100
1450
880
830
1250
1500
1600
4-Φ13
LK-AV10H/100
LK-AV15L/120
1550
950
900
1350
1500
1600
4-Φ13
LK-AV12H/120
LK-AV20L/160
1750
950
900
1550
1500
1600
4-Φ13
LK-AV15H/160
LK-AV25L/200
1750
950
900
1550
1500
1600
4-Φ13
LK-AV20H/200
LK-AV30L/240
2120
1110
1050
1920
1580
1680
4-Φ13
LK-AV25H/240
LK-AV30H/270
2300
1110
1050
2100
1580
1680
4-Φ13
LK-AV40M/300
2450
1100
1050
2250
1580
1680
4-Φ13
LK-AV35H/300
Application:
1.Refrigeration industry,cold room project;
2.Agricultural,food,restaurant,chemical industry etc area.
Related Products
Packaging & Shipping
Packing Details:
—Wooden or Polywood Case —All products are inspected carefully by QC before delivery.
Our Services
Delivery time: 15 working days after the payment MOQ: —1 set —If order more, the price will be more favorable
