High quality fully automatic EPP styrofoam vacuum shape molding machine for packing line

Product Overview

Description







    SPZ-FPS Series epp foam box molding machine



1. Feeding methods:
    Feeding by pulse;
    Feeding by negative pressure;
    Feeding by back pressure;
    Feeding assisted by currents of wind.
2. Smart proportional valves of high precision are in control of such processing as feeding, heating and mould unloading.
3. Intensive hydraulic power system offers the integration of powering and pressurization, thus securing convenience for maintenance;

4. Structure for quickly-replacing mould ;
5. Self-equipped water tank (steam chest) ;
6. Precise joint retention accuracy;
7. Frames of high rigidity, promise and secure enduring production in responsive to EPP industry;
8. Various devices for safety.



Item		SPZ870FPS	SPZ1070FPS	SPZ1270FPS	SPZ1470FPS	SPZ1670FPS	SPZ1870FPS
Max Product Size		870×670mm	1070×870mm	1270×1070mm	1470×1270mm	1670×1270mm	1870×1670mm
Max Product Height		400mm
Outside Dimensions	L × W× H	6500×2400 ×4450mm	6500×2600 ×4650mm	6500×2800 ×4850mm	6500×3000 ×5050mm	6105×3200 ×5250mm	6500×3400 ×5250mm
Weight		8.0t	9.0t	11.5t	12.5t	14.0t	16.0t
