Product Specification
TS008O sewing thread winding machine with semi-auto oiling device is suitable for winding sewing thread, polyester, nylon, embroidery thread.It is with solid frame , high quality spare parts and perfect design.


Main features
1. The winding speed of each spindle is 100 to 1000 meters per minute which is adjusted according to the yarn.
2. The take-up cone is beautiful and with high quality.Low noise when is works.


If the bobbin length is 2.5 ~ 5 inch,one spindle with two heads. If the bobbin length is 5~7inch,one spindle with one head.
| Model Number | TS008O |
| Brand | TANGSHI |
| Place of Origin | Jiangsu, China (Mainland) |
| Application | Winding Thread |
| Automatic Grade | Semi-Auto |
| Memory Capacity | 999999m |
| Production Ability | High Speed |
| Speed | 100-1000m/min |
| Driving | Independence Control |
| Tension | Electronic tensioner |
| Bobbin Type | Y-Shape, Cone, Cylinder 2.5inch-6inch, Customized |
| Auto Stop Device | Included |
| Package Diameter | 115mm |
| Control | Touch Screen Control |
| Lubrication System | Auto-Recycle Lubricate |
| Bobbin Nos. | 4 Spindles with 8 bobbins/4 bobbins |
| Certification | ISO9001:2008/CE |
| Power(W) | 1kW/set |
| Voltage | 380V,220V |
| Weight | 650KG |
| Warranty | 1 year |
| After-sales Service | engineer service to available machinery |
| Dimension(L*W*H) | 2250*1050*1650mm |
Packaging&Shipping
Before loading,the machines are covered with waterproof plastic first,then packed in solid wooden case.

Jiangsu Tangshi Textile Machinery Group Co., Ltd was an experienced and professional manufacturer, it already has 30 years' experience of producing drum winding machines, with advanced technics and production equipments it can output more one thousand winding machines annually. after these years hard work and faith cooperation, Jiangsu Tangshi Textile Group Co., Ltd got a good reputation. our products like GA014 series soft and tight winding machine, TS008 semi-automatic soft and tight winding machine, TS230,280,290,300 big take-up winding machine. and we also can customize machines according to the customers' special demands. we service the textile industry in conformance with the aim of “professional produce, faith operation, reputation brand ”. The products are widely sold at domestic and also export to south-east asia countries gradually.To supply all kinds of winding machine is our company's feature, good quality and in time deliverly is our promise. sincerely hope we can go forward hand in hand and set up bright life together!Winding machine------------Jiangsu Tangshi Textile Machienry Group Co., Ltd will be your best choose!
