Samsung Fridge Thermo Bimetal Thermostat DA47 10160E

Product Overview

Description



Samsung Fridge Thermo Bimetal Thermostat DA47-10160E

Some defrost systems use a thermostat (a bi-metal switch) to prevent the defrost heater from overheating. The switch is normally closed. During a defrost cycle, the defrost heater causes the metal alloy in the switch to warm and as it does it curls back and breaks the circuit. As the metal cools, it makes a circuit again and the defrost heater starts heating again (as long as the defrost timer is in the defrost cycle).



Applications
- Refrigerator/ Freezer
- Electrical Blanket
- Showcase
- Ice Machine
- Electrical Stove

Features
- Ultra slim type
- Ideal for where space is premium
- Plastic seal available for hermetic protection
- Leadwire and terminal can be attached upon order
- Double contacts for extra reliability
- UL, VDE and TUV certificated
- Environmental friendly towards RoHS, REACH



Open temperature: 11C, Close temperature: 0C.



Use	Temperature control/Overheat protection
Reset type	Automatic
Base material	Resist heat resin base
Electrical Rating	15A / 125VAC, 7.5A / 250VAC
Max. Operating Temperature	150°C
Min. Operating Temperature	-20°C
Tolerance	+/-5 C for open action(Optional +/-3 C or less)
Protection class	IP65
Contact material	Double Solid Silver
Dielectric Strength	AC 1500V for 1 minute or AC 1800V for 1 second
InsulationResistance	More than 100MW at DC 500V by Mega Ohm tester
Resistance Between Terminals	Less than 100mW
Diameter of bimetal disc	Φ12.8mm(1/2″)
Approvals	UL/ TUV/ VDE/ CQC
Terminal type	Customized
Cover/Bracket	Customized

















Samsung Fridge Thermo Bimetal Thermostat DA47-10160E
