New Design Wall Through Customized Full Function Bank ATM Machine
- Category: >>>
- Supplier: Shenzhen Rotron Technology Co. Ltd.
Share on (60651586750):
Product Overview
Description
New Design Wall Through Customized Full Function Bank ATM Machine | |
Components | Detailed Discription |
Computer (Advantech/Rocky/Evoc/Seavo) | Motherboard:Industrial board |
CPU:Intel G2030/I3/I5/I7 | |
RAM:DDRI 4GB; Hard Disk:500 GB | |
6RS-232 Ports,8 USB Ports,1 LTP, 1 VGA,1LVDS,1 10/100M Net Port | |
Net Card, Sound Card,Integrated Display Card | |
Computer case and power supply | |
Monitor(LG/Samsung/Auo) | Brightness: 300cd/m2 |
Contrast: 450:1 | |
Response Time:5ms;Dot pitch: 0.297; | |
Max. resolution: 1280*1024 | |
Touch Screen | High Transparence, high precision and durability |
Thickness: 6mm, Max: 4096×4096 | |
Surface Hardness: Mohs' hardness rating of 7 | |
Bank Card Reader | Three in one motorized card reader. Takes card into reader, magcard/IC card reading - writing;Electric protection valve; Eject the card when abnormal and pwr-failure |
Metal Keypad (Encrypted Pin Pad) | 16 Keys Encrption Metal Keyborads; Number Keys: 10; Function Keys: 6 ; PCI compliant; |
2*Functional Keybars | High-quality stainless steel side keypad;Lifespan:>1 million operations per key;Activate force:65g;Key press force:3~5N. |
Cash Dispenser | Piece dispensing module,Intelligent Double Detection,High Performance Feed, with 1 rejection cassette 4 Smart Cassettes, Max. Cassette capacity: 3000notes. |
Journal/Log Printer | Dot Matrix Printer,Automatic Paper Cutter; Paper width: 58mm or 76mm; Speed:5.6 line/Second( for 58mm ),4.4 Lines/second( for 76mm) |
Receipt printer | Thermal Printer;Automatic Paper Cutter; Paper in Width:80mm; Speed:150mm/Second; Invoice Print; with Black Mark Sensor |
Door Access Alarming System | Will auto alarm when somebody illeagally break into the machine or move the cash cassettes |
Maintenance Light | Inside LED light, it's on when open the door, off when close the door; |
3*Pinhole Camera | Image Sensor: Color 1/3 OVCMOS,Horizontal Resolution: 420TV light;TV system: PAL/NTSC |
UPS | Supply 10-20 minutes |
Speakers | Left and right bi-channel; amplified output; Multimedia speaker |
Enclosure | Durable steel frame, Power coated; Slim and smart design; Easy to install and operate; Moistureproof,Antirust,Anti-acid,Anti-dust,Static free,Graphics on front of kiosk, color painting and LOGO printing upon request; |
OS Software | Microsoft Windows 7 Pro (Trial version), all hard drivers are available |
Optional configuration | |
DVR& Hardisk | 4 channels digital ATM bank dedicated DVR, high quality image,support USB storage device; Harddisk: SATA interface,1T |
RFID/Contactless Card Reader | Interface:USB, antenna inside,CCID compatiable |
ID Card Reader | In accordance with ISO14443 Type B standard, recognize the information from ID card |
Packaging
Each kiosk is packed by film,bubble foam and woodern case to perfectly keep kiosk well after long distance transportation.
Shipment
Each kiosk can be shipped by air, sea, and Express like Fedex/DHL/UPS/TNT etc, which is based on customer's request.
Workshop show
Shenzhen Rotron Technology Co., Ltd. has our own factory, which covers more than 3000 square meters. We have four production line, and establish strict quality control rules. All the production are carried out in ISO standards. We win the good reputation from our customers by focusing on each order in the production process.
Why choose us?
1. Over 10 years experience in creating attractive professional kiosks.
2. With a strong R&D team consists of 8 skilled structural engineers, technicians and designers who have been in kiosk/ATM industry over 10 years.
3. Our kiosks win customer good reputation by our innovative & smart design, exquisite craftwork and excellent working performance.
4. Technical support can be provided at any time.
5. With one year warranty.
