High Quality Atmoshpere Furnace Vacuum and Inert Gas Furnace Atmosphere Muffle Furnace
Product Description
Furnace Structure & Chamber:
High purity fibrous alumina insulation for maximum energy saving 60-80% less power consumption than old style. The furnace can insert all inert gas,such as: mixed gas,nitrogen,carbon dioxide,water vapor,argon gas and oxygen etc.
Heavy duty double layer structure with cooling fan to keep furnace exteriors safe to touch.
Atmosphere Furnace Selection Table:
Model No.
Door open
Max. Temp
(.C)
Internal size(mm)
DXWXH
Volume
(L)
Max. power
(kw)
Power supply
Therm couple
Heat-up time(mins)
SA2-2-17TP
Side
1700
100x100x100
1
2
220V
B type
60
SA2-3-17TP
Side
1700
150x100x100
1.5
3
220V
B type
60
SA2-4-17TP
Side
1700
200x150x150
4.5
4
220V
B type
60
SA2-9-17TP
Side
1700
300x200x200
12
9
380V
B type
60
SA2-16-17TP
Side
1700
400x300x300
36
16
380V
B type
60
Continuous operation temperature is 100.C below Max. temperature. Get One Offer (Click here)
Atmosphere Furnace Details Specification :
Rated Voltage & Power:
AC 380V 50/60Hz, 9kw
Inner Chamber Size:
D300xW200xH200mm, 12 Liters
Max. Temperature:
1700.C for short time ;
Continuous Working Temperature:
1600.C Max.
Max. Heating Rate:
0-30.C /min, suggest to be 10.C/Min;
Temperature Controller:
PID automatic control and auto-tune function,
30 programmable segments for precise process.
Vacuum pump
-0.1 Mpa
Can insert gas
mixed gas,nitrogen,carbon dioxide,water vapor,argon gas and oxygen etc.
Temperature Accuracy:
+/- 1 .C.
Heating Element:
MoSi2 heater .
Thermocouple:
B type
Standard Parts:
Crucible tongs 1pc, high temperature gloves 1 pair , one user manual.
Warranty: One year limited warranty with lifetime support, excluding heating element,cooling fans,thermocouple and ceramic tube damaged by user.
Attention: Any damages caused by the use of corrosive and acidic gases, and any damage from wrong operate and use are not under the coverage of One Year Limited Warranty.
Packaging & Shipping
Shipping way : By Courier / By sea / By Air /By Train Optional, depend on clients' demad of time and cost.
Shipping terms: Support EXW /FOB/C&F /CIF/ CPT/CIP /DDU /DDP terms...
Even for some countires with high taxes and some Remote areas, we can ship goods to your Door address and including taxes.
