SMUN Waterproof Non isolated SDS 12S2815 12VDC to 28VDC 15Amp DC to DC Voltage Converter

DC12V to DC28V 15A Power Converters 420W

Features

1. 100% full power & stable current output

2. 100% Imported components

3. Wide input voltage from 10-25Vdc

4. 100% waterproof & anti-shock protection, Ultra compact size, light weight

5. Industry grade DC12V to DC28V step-up converter, efficiency up to 96%

6. Certificates: CE

7. Waterproof level: IP68

8. Die-cast aluminum shell, epoxy potting, Cooling by free air convection,

9. Protections: Over-current, Over-voltage, Over-temperature and Over-load

Auto-recovery when device is back to normal operating

10. Non-Isolated Module

11. 1 year warranty, lifetime up to 100,000 hours.

Specifications

Model

SDS-12S2815

Input rated voltage

12V DC

Input voltage range

10-25V DC

Efficiency

97% (half load) ; 96% (full load)

Output voltage

28V DC

Output current

15 Amps

Output rated power

420 Watts

Output peak power

125%

Voltage regulation

< 1%

Load regulation

< 2%

Ripple (full load test)

< 180mV

No-load current

< 30mA

Working Temperature

-40°c ~ +80°c

Waterproof rating

IP 68

Protections

Over-load, Over-current, Over-temperature, Over-voltage

Machine size

100*80*39mm

Package size

126*91*46mm

N. Weight

470g

W. Weight

500g

Cooling way

Free air convection

Certifications

CE

Other

White box packing
