Shanghai Feiyu Factory Price Automatic Hardware Items Wire Nails and Bolts Small Bag Pouch Packing Machine
- Category: >>>
- Supplier: Shanghai Feiyu Packaging Machinery Co. Ltd.
Share on (60652622536):
Product Overview
Description
Products Description
Automatic Hardware Items Wire Nails and Bolts Small Bag Pouch Packing Machine:
1. Application: Screw, bolt, washer, nut and other kinds of regular shape fastener products.
2. Adopting spacking counting and fiber optics re-inspection or completed fiber optics counting, suitable to mixing packaging for1~40 varieties of items.
3. Machine owns many patent technology, such as technology of fiber optics counting(patent No. ZL2010 20695240.5), weight checker(patent No. ZL201110083021.0; practical new type patent No. ZL201120094492.7)
4. Solid sealing, smooth and elegant bag shape; high efficiency and durability, can be equipped with exhaust device, printer,labeling machine, transfer conveyor and weight checker.
5. Automatic ordering, counting, packing and printing etc. Easily adjust the quantity of screws in the bag, set the quantity of bags what you need, when meet, the machine will be stop automatically.
1. Application: Screw, bolt, washer, nut and other kinds of regular shape fastener products.
2. Adopting spacking counting and fiber optics re-inspection or completed fiber optics counting, suitable to mixing packaging for1~40 varieties of items.
3. Machine owns many patent technology, such as technology of fiber optics counting(patent No. ZL2010 20695240.5), weight checker(patent No. ZL201110083021.0; practical new type patent No. ZL201120094492.7)
4. Solid sealing, smooth and elegant bag shape; high efficiency and durability, can be equipped with exhaust device, printer,labeling machine, transfer conveyor and weight checker.
5. Automatic ordering, counting, packing and printing etc. Easily adjust the quantity of screws in the bag, set the quantity of bags what you need, when meet, the machine will be stop automatically.
Product specification:
Model | FY-240C | FY-420C | |
Packing size | L: 30-180mm, W: 50-140mm | L: 50-300mm, W: 50-200mm | |
Max film width | 300mm | 420mm | |
Packing material | PA/PE, PP/CPP, PET/PE | ||
Counting capacity | 1-20pcs/bag; 1-40 kinds/bag | ||
Packing speed | 10-60 bag/min | ||
Power | AC220V/50HZ/2LW | ||
Machine size | L*W*H: (n/2*600+2200mm)* 1500* 1650mm, n=the Qty of vibration bowl | ||
Operation Process
Details Description
Packaged Bag Display
Scope of Application
Packaging & Shipping
Order Process
Why Choose Us
1. Dual inventers control, bag length can be set and cut in one step, saving time and bags.
2. Computer interface operation, convenient and quick parameter setting.
3. PLC control, stable performance available for upgrade.
4. There are many patented technologies, such as technology of fiber optics(Patent No. ZL2010 20695240.5), weight checker(Patent No. Zl201110083021.0).
5. Self failure diagnosis, clear failure display; positioned stop function, without knife sticking and film wasting.
6. Using double encoder enables stable performance.
7. Strengthened blade holder makes compact sealing.
8. Can be equipped with exhaust device, printer, labeling machine, transfer conveyor and weight checker.
Selected code system achieves credible Packaging.
10. Simple and automatic packaging achieves high speed and saving labor.
11. Optional material-cutting proof device, guarantee for using.
12. Multipurpose packaging, suitable for various packaging to similar type of product.
13. Alternative English and Chinese language display.
2. Computer interface operation, convenient and quick parameter setting.
3. PLC control, stable performance available for upgrade.
4. There are many patented technologies, such as technology of fiber optics(Patent No. ZL2010 20695240.5), weight checker(Patent No. Zl201110083021.0).
5. Self failure diagnosis, clear failure display; positioned stop function, without knife sticking and film wasting.
6. Using double encoder enables stable performance.
7. Strengthened blade holder makes compact sealing.
8. Can be equipped with exhaust device, printer, labeling machine, transfer conveyor and weight checker.
Selected code system achieves credible Packaging.
10. Simple and automatic packaging achieves high speed and saving labor.
11. Optional material-cutting proof device, guarantee for using.
12. Multipurpose packaging, suitable for various packaging to similar type of product.
13. Alternative English and Chinese language display.
Our Service
Pre-sales Services:
1.Many professional packing videos, give you direct feeling about our machine.
2.Free packing solution from our chief engineer.
Medium-sales Services:
We have the trained team to follow your orders methodically to guarantee the products can be finished on time with high quality.
After-sale Services:
1.Manules / Videos of machine installation, adjusting, setting, maintenance are available for you.
2. If any problems happend and you can not find out the solutions, Telecom or Online face to face communication available 24
hours.
3. Our engineers & technician are available send to your countries for services if you agree pay the expenditure.
4. The machine will have one year guranty for machine. During the warranty year if any of the parts broken not by man-made. We
will free charge to replace the new one to you. The warranty will begin after the machine send out we received the B/L.
5. We have an independent team for after-sale service. Any emergency please call the saleman or our after-sale's manager. On-site
repair or instructions are also available.
1.Many professional packing videos, give you direct feeling about our machine.
2.Free packing solution from our chief engineer.
Medium-sales Services:
We have the trained team to follow your orders methodically to guarantee the products can be finished on time with high quality.
After-sale Services:
1.Manules / Videos of machine installation, adjusting, setting, maintenance are available for you.
2. If any problems happend and you can not find out the solutions, Telecom or Online face to face communication available 24
hours.
3. Our engineers & technician are available send to your countries for services if you agree pay the expenditure.
4. The machine will have one year guranty for machine. During the warranty year if any of the parts broken not by man-made. We
will free charge to replace the new one to you. The warranty will begin after the machine send out we received the B/L.
5. We have an independent team for after-sale service. Any emergency please call the saleman or our after-sale's manager. On-site
repair or instructions are also available.
Feiyu Introduction
Company Profile
Shanghai Feiyu packaging machinery Co., Ltd., established in 2008, has been devoted to counting and packing machinery manufacture. Our packing machine widely use in:
-Fastener(screw, nut, washer, nail, small hardwares, etc.)
- Furniture spare parts
- Plastic pipe fittings (pipe, joint etc.)
- Auto Parts
- Machinery and appliance spare parts
- Clothes parts (button,slider etc.)
- Toy industry
And other solid material counting/ weighing and packing.
It can pack the same items or mixed items in the packs by quantity. Part of Feiyu-Pack products have obtained CE certificate.
-Fastener(screw, nut, washer, nail, small hardwares, etc.)
- Furniture spare parts
- Plastic pipe fittings (pipe, joint etc.)
- Auto Parts
- Machinery and appliance spare parts
- Clothes parts (button,slider etc.)
- Toy industry
And other solid material counting/ weighing and packing.
It can pack the same items or mixed items in the packs by quantity. Part of Feiyu-Pack products have obtained CE certificate.
