HVAC air duct making manufacturing machine / auto duct line pipe making machine

Product Overview

Description

HVAC air duct making manufacturing machine / auto duct line pipe making machine

YOUTUBE VIDEO

https://youtu.be/swc5aHGpkMw



Main import Configuration:

Basic Configuration:

1. Beijing Huade+Taiwan hydraulic system.   2. Japan Omron encoder.      3. Taiwan Hiwin linear guideways.      4. Schneider electrical system.

1. Two electric coil cradles, 4 material trays.   2. One rack.     3. One host (line 2 host).      4. Two stainless steel roller convey platforms.      5. One fixed joint locking machine.       6. One duplex TDF flange forming machine.      7. One duplex angle steel flange forming machine.    8. One servo feeding platform.      9. One hydraulic folding machine.      10. One set of computer controlling system.



Main Technical Parameters:

Model	Sheet thickness (mm)	Max width (mm)	Max working speed (m/min)	Max weight  of coil (T)	Dimension L*W*H (mm)	Power (kw)	Weight (T)
ADL-5U-1300	0.5-1.2	1300	15	7	12000*5500*1500	30	10
ADL-5U-1500	0.5-1.2	1500	15	7	12000*5900*1500	30	11
