Germany Ipg Laser 1000W Fiber Laser Cutting Machine
- Category: >>>
- Supplier: Guangzhou Great Year Laser Technology Co. Ltd.
Share on (60655054936):
Product Overview
Description
Germany Ipg Laser 1000W Fiber Laser Cutting Machine
Technical Parameter
| GY-1530FD machine's technical parameters | |||
| Floor area | About 7650*3520mm (excluding loading and unloading area) | ||
| Allow material Maximum cutting area | 1500*3000mm | ||
| Machine Gross weight | 8000KG | ||
| Power supply requirements | 380V/ 50Hz | Total power | 20KW |
| Environmental requirements | Temperature range: 10-35 ºC Humidity range: 40-85% | ||
| 1, 000 meters above sea level, the use of environment non-flammable, explosive, magnetic, strong earthquakes | |||
| Equipment moving system parameters | |||
| Cutting speed, acceleration | 0-50m/min | ||
| 0-3000mm/s2 | |||
| Air-way speed, acceleration | 0-50m/min | ||
| Positioning accuracy | <0.03mm/m | ||
| Drive System | Adopt Japan YASKAWA servo motors drive | ||
| Transmission | All use high precision helical rack and pinion | ||
| Feedback and transport control systems | Dedicated transport and control system | ||
| Ventilation system | Fixed lower ventilation | ||
| Workbench Type | Rack Workbench | ||
| Circuit and protection system | Standard Design | ||
Main laser cutting functions
| GY-FD Series Laser Cutting macine main function | ||
| No. | Function | Description |
| 1 | Height Follow-Up | Torch Move Up And Down According To Plate Height |
| 2 | Power Control | Laser Power Control According To Slope |
| 3 | Reverse Function | Reverse To Execute NC Program |
| 4 | Breakpoint Return | Return To Breakpoint After Recovery |
| 5 | Multi Piercing | Pulse, Blasting, Progress, High-Speed |
| 6 | Lead Line | Set Lead Line Parameter |
| 7 | Auto Edge-Finding | Find Cutting Piece Coordinate Automatically |
| 8 | Leapforg Function | Leapforg To Improve Cutting Efficiency |
| 9 | Common Line | Common Line To Improve Cutting Efficiency |
| 10 | Marking Function | Mark Any Shape On Plate |
Welcome to visit our factory in Canton!
