Thread connection SUS316 Single acting Pneumatic Angle seat valve

Cylinder material

Polyamide PA ,stainless steel

Pneumatic accessories

Limit switch, locator, solenoid valve, filter relief-pressure valve, manual operating device

Medium temperature

PTFE:-30~180°C   F46:-30~+220°C

Environment temperature

-30~80°C

Nominal pressure

1.0~1.6MPa

Nominal diameter

DN15-100mm

Body construction

One-piece

Body material

304,316, 316L

Spool pressure

304,316, 316L

Seal material

PTFE,F46

Interface

(inch)

Inner

bore(mm)

KV value(m3/h)

The maximum working Pressure(bar)

Air pressure

(bar)

Actuator size(mm)

Flow direction

G3/8

10

3.7

0-16

4.0

50

Over the top of the seat

G1/2

15

4.2

0-16

2.7

50

G3/4

20

8.0

0-16

2.7

50

G1

25

19.0

0-16

2.0

63

G1 1/4

32

27.5

0-16

2.0

63

G1 1/2

40

42.0

0-16

2.0

63

G2

50

52.0

0-16

2.0

80

G2 1/2

65

77.0

0-14

1.6

100
