Forest fire protection 10km long range ptz zoom surveillance security optical fog penetration cameras Support solar power supply
- Category: >>>
- Supplier: Shenzhen SafeEye Technology Co. Ltd.
Share on (60655782015):
Product Overview
Description
Product Description
Forest fire protection 10km long range ptz zoom surveillance security optical fog penetration cameras Support solar power supply
Overview
S-PTZ5200LF long-range fog penetration camera is designed for bad weather conditions. With the intelligent photoelectric linkage, optical and AFR image processing technology, the camera uses the long wavelength light to enhance image details in foggy, moist and dusty environment, and increase the effective view distance by 1.7 to 2.3 times.
Optional 200mm~1000mm telephoto zooming lens and 440000 pixel(D1)/ 2 megapixel (1080P)visible color to B/W CCD, and with the 360°continuously rotation platform, the camera can monitor a region of 2km~10km clearly.
With built-in technical grade electronic control system, the camera can complete functions like zooming, focusing and video switch easily. One integral aluminum alloy housing and IP66 ingress protection ensures its proper functioning outdoor.
Key Features
- Feature
1, Optical filtering and image processing technology, color and B/W fog penetration mode.
2, Exclusive AFR imaging enhancement algorithm can correct the image in black/serious backlight/foggy environment and increase frame frequency to 30 fps. With the AFR, the camera can adjust image contrast in foggy environment and enhance image details.
3, Optional 300mm~1000mm zooming lens and SD 440000 pixel/HD 2 megapixel CCD, CMOS camera.
4, 360°continuously rotation platform with 20kgs/50kgs duty.
5, One integral aluminum alloy housing, waterproof, IP66 ingress protection, dustproof, rainproof.
Application
Seaport&airport security, lake&river monitoring, mariculture monitoring, oilfield security, forest fire prevention, city security.
Technical specification:
| Model | S-PTZ5200LF | ||||
| CCD | 1/2.8'' 0.01lux low illumination color to B/W CCD, 2 megapixel, 1080P, video format H.264 | ||||
| Lens | 2.0Megapixel HD, motorized zoom,auto iris | ||||
| Zoom | 10~200mm | 12~320mm | 15~528mm | 25~750mm | 20~1000mm |
| Detection | 1.5km | 2~3km | 5~7km | 8km | 10km |
| Fog penetration | Optical filtering and AFR image processing technology | ||||
| Mode | B/W color mode | ||||
| Housing | One integral aluminum alloy housing, waterproof, weatherproof IP66 | ||||
| Load duty | 20kg | 50kg | |||
| PT | Pan: 360o continuously, Tilt: +45°~-75°, display angle and transmission back function. | Pan: 360ocontinuously, Tilt: +45°~-45°, display angle and transmission back function. | |||
| Rotation speed | Pan: 0.01~60°/S, tilt: 0.01~30°/S | Pan: 0.01~30°/S, tilt: 0.01~15°/S | |||
| Interface | RJ45*1 (video +control), AC24V*1 (Optional RS485 with angle and transmission back function) | ||||
| Power supply | AC24V±10%,50Hz,5A | ||||
| Ingress protection | IP66 | ||||
| Operational temp. | -25℃~+55℃(-40℃ optional) | ||||
| Weight | ≤45kg (included PT ) | ||||
| Dimension | 492x260x477mm | ||||
temperature detection sensor PTZ thermal imaging camera with Model S-TPT5200ZT
Our Services
- The product is based on Ex-works for 1-50pcs, FCA shenzhen for 50-500pcs, FOB shenzhen for above 500pcs.
- Payment term:100% payment in advance before shIpment (T/T, Western Union ,paypal,cash or any other means at your convenience)
- Delivery Time:sample order: 1-3 working day, Normal order:longer than 3 working days according to the order quanity
- All the above products have CE ,FCC and ROHS certificates
- Welcome OEM & ODM order,MOQ for OEM is 50pcs/model
- Power adapter isn't included in above prices, it's optional
- Price Validity: 30 days from issuing date.
- Warranty: 2 years after receiving goods,unlimited lifetime Technique support.
- If quanity more than 100pcs one model, we will free supply some camera parts for preapre exchange
