Foot Operated Pneumatic Orbital Spin Riveting Machine For Hardware

Product Overview

Description

 Description:

Model	JZ-9206A	JZ-9206B	JZ-9206C
Air consumption	4.8NL	4.8NL	4.8NL
Stroke of spin head	20-45mm	20-45mm	20-45mm
Riveting capacity	Solid rivets:0.5-5mm Hollow rivets:1-8mm	Solid rivets:1-8mm Hollow rivets:1-15mm	Solid rivets:1-9mm Hollow rivets:1-25mm
Throat depth	130mm	130mm	130mm
Power	1/4HP 1 or 3 phase	1/4HP 3 phase	1HP  3 phase
Gauge pressure	1-7kgf/cm2	2-7kgf/cm2	2-7kgf/cm2
Max.output	720kgf	720kgf	1170kgf
Working cycle time(second)	0.5-5	0.5-5	0.5-5
Machine dimensions(L*W*H)	450*450*1050mm3	550*550*1150mm3	650*650*1250mm3
Net weight	90kg	105kg	150kg
Gross weight	105kg	130kg	180kg
Packing	Wooden cases	Wooden cases	Wooden cases
