aluminum extrusion press machine,aluminium extrusion press manufacturers,extruder machine aluminum

NO.

Item

Specification

Remarks

1

Working Pressure

21Mpa

2

Maximum Main Force

12500KN

3

Backward Force

58T

4

Locking Force

340KN

5

Shearing Force

380KN

6

Speed of Press

0.3-11mm/s

7

Fast Forward Speed

389mm/s

8

Fast Backward Speed

353 mm/s

9

Locking Speed

272mm/s

10

Open Speed

165mm/s

11

Speed of Shearing Down

331mm/s

12

Speed of Shearing Up

544mm/s

13

Container Size

Inner Diameter:Φ150-Φ200mm

L:650-700mm

14

Billet Size

Diameter: 6”

L:600-650mm

15

Total power of motors

55KW*3

16

Heating Power Of Container

24KW

17

Operating Mode

Manual or Auto Single Stroke

18

Dimension of the press

9.5 m *3.3 m *3.5m
