Three phase ATS controller dual power automatic transfer changeover switch

Product Overview

Description

Three phase ATS controller dual power automaic transfer changeover switch

Model	Pole	YES1-32NA				YES1-125NA
A	2P	216				237
	3P	243				274
	4P	270				311
B	2P	196				217
	3P	223				254
	4P	250				291
E		12				20



Technical Parameter of (NA) Type ATS

Model	YES1-32NA			YES1-40NA			YES1-63NA			YES1-125NA
Rated current(A)	12,25,32			40			63			125
Operating current(A)	3.5
Rated short time current(kA)	5
Service life Mechanical	8000
Service life Electric	3000
Pole	2P	3P	4P	2P	3P	4P	2P	3P	4P	2P	3P	4P
Weight(kg)	4.2	4.7	5.2	5	5.5	6.5	5	5.5	6.5	5	5.5	6.5
Operating Cycles(s/time)					10



NOTE: For more detail information you wanan know, pls feel free contact with me. Thanks!
