cnc automatic copper tube shrinking/expanding/necking machine

Product Overview

Description



                                                         the performances of the machine:

         1. KSK-III four stations pipe end forming machine is a specialized semi-automatic equipment for processing flaring and necking,making horn mouths and bosses of the air-conditioners,water heaters, refrigeration.

        2.it control by PLC(or cnc system),by hydraulic pressure to the medium,position by the servo,

        3.hand pressed into the lubrication system,die left and right position can be adjusted by plus or minus servo,Make sure the die and the work-piece concentricity shift servo motor,hydraulic equipped with air-cooled.

        4.This machine with low cost, simple construction ,easy operation ,stable motion ,precise process, good consistency, convenient adjustment and high production efficiency.

       5.It is currently the cost-effective product for the process of the refrigeration pipe, pipe-end forming , nozzle process and shaping, which is with high automatic level too.



                                                                      our serive:



                                the outside drawing of the machine:





                                 the product sample:





                                  the main parameter:
