IPTV Encoder 24Channels VGA ASI Full HD 1080P RTMP MPEG4

Product model

JX-3610 SDI HD encoder

Input

1 channel SDI input,1 channel 3.5 audio input

Output

1 channel IP signal output

Video

Input resolution

1920x1080p/1920x1080i/1280x720p/720*576i/640*480i And other conventional resolution

Coding standard

H.264

Coding level

    H.264 BASELINE PROFILE

H.264 MAIN PROFILE

H.264 HIGH PROFILE

Encoded size

640*360~1920*1080(Can customize)

Video bit rate

Rate control:CBR/VBR 16KBIT/S~12MBIT/S

Video frame rate

30/60

OSD

Character ,images

Audio

Input selection

1 channel embedded audio SDI, 1 channel 3.5MM independent audio Support audio gain

Audio coding

AAC/MP3/G711

Audio bit rate

64Kb/s~384Kb/s

Sampling rate

32000,44100 ,48000etc

IP

output

1 RJ 100M / 1000M adaptive Ethernet port, TS stream standard, dual-stream, ONVIF protocol

System

Network protocol

Supports HTTP, RTSP, RTMP, UDP, HLS multicast, unicast

Configuration management

Support IE configuration, remote upgrade

The common use

Power supply

12V~2A

power consumption

5W

Size

146mm * 122mm * 42mm(length*width*height)

Operating temperature

-20℃+ 60℃

Working humidity

<90%,Non-condensing

Weight

0.3KG
