1.Details of trade assurance single screw extruder pasta macaroni machine:
1).This production line adopts potato starch, potato powder and corn starch as main materials, to produce a variety of twice extrusion ones in different shapes, which are popular in the market, such as crisp pea, shell, screw, square tube, round tube, and wave. This line is characterized by unique technique, rational configuration, high automation and stable performance.
3. Voltage in China: Three phases: 380V/50Hz, Single phase: 220V/50Hz, we can make it according to customers' Local voltage according to different countries 4. Machines materials: All the machines are made by stainless steel to prolong the service life.
5.Specification of the single screw extruder pasta macaroni machine:
Model
DLG100
DLG150
Install Power
110KW
180KW
Consumption Power
77KW
126KW
Output
120-150KG/H
220-250KG/H
Dimension
22000×1300×2200M
26000×1300×2200M
Jinan Saibainuo Machinery Co., Ltd, professional food machine manufacturer in China since 2004, quality is our culture, time is our gold, we have professional engineers produce nice quality machines in short time, also have special team work for sales service 24*7 to help you slove any kinds of problem.
Detailed Images
Name: high speed mixer
Dimension(m): 1.1×0.8×1.4 Motor Power: 4KW Speed: 400rpm Throughput: 30kg per loading (5-6 minutes per loading) Functions: mix raw powder material with water Features: 1. stainless steel material(1.5mm). 2. no material leak 3.High speed can mix material better than slow speed mixer.
Name: screw conveyor
Dimension(m): 3.2×0.6×0.7 Motor Power: 1.1KW Screw speed: 300rpm convey height range:1.5~2.5M barrel diameter: Φ141mm Function: Power material can be conveyed in the stainless steel roller to the feeder of extruder without leaking, dust and pollution; Features: stainless steel material(1.5mm)
Name: single screw extruder
Dimension(m): 2.6×1.0×1.3 Total power : 40kw Main Motor Power:22KW Feeder motor:0.75kw Cutting motor: 0.75kw Heating power:15kw Screw diameter:Φ100 mm Screw Material: 38CrMoAl alloy steel System: Feeding system Extruding system Heating system Cutting system Lubrication system
Namer: cutting machine
Dimension(m): 2.2×0.6×1.2 total Power: 1.5KW Function: To pull the pasta and cut them
Name: dryer(we also have gas/steam/diesel dryer for your selection)
Dimension(m): 8.4×1.3×1.8 Heating Power:80kw Motor power:0.75kw Belt speed:0.1-10M/minute Temperature: 20-200℃ Function: There are Seven layer inside,each layer is 8 meters long, it can save space and energy. Electricity heating,used to bake and dry food. Features: The net belt running speed can be controlled by Inverter, to change the food drying time in the dryer. Heating adopts the electric heating It has automatic temperature Control system. The belt and the cover are all stainless steel
Name: cooling conveyor
Dimension(m): 5.0×0.7×1.1 Motor Power:1 KW Function: Cool the food after drying , make the food suitable for packing. Feature: Stainless steel material
Certifications
Our Service
Pre-sale service: 1.Related machines's technical parameter will be supplied to customer. 2.According to customer's factory size, factory layout can be provided in advance. 3. According to customer's material cost, general formulation can be prepared well. 4.Special machine can be supplied as customer's request. 5.Professional Advice about Market, machines, processing , materials, packing can be supplied 6. Suggesting professional ship agent or helping book ship as customer request. After sale service: 1.Allocation chart as the buyer's request will be supplied. 2.Operation manual will be supplied after shipment. 3.One year warrantee, life time maintenance with cost price. 4.Free easy broken spare parts will be sent with container . 5.First installation can be done by engineer. 6.Training workers in customer's factory.
Packing & Delivery
Packaging & Shipping:
1).Packaging: daub coal oil on the surface to protect the machine from moisture, Then cover with plastic film.Finaly pack them with wooden case. 2)Customer's requirement is available.
3).If you want to know the transportation cost: by air-please tell me your airport name; by express-please tell me your detailed address(including zip code,house number,street,city,country); by ship-pls tell me your delivery port.
