china import Yellow solar 3m diamond grade sign solar Highway traffic signs
china import Yellow solar 3m diamond grade sign solar Highway traffic signs
china import Yellow solar 3m diamond grade sign solar Highway traffic signs
china import Yellow solar 3m diamond grade sign solar Highway traffic signs

china import Yellow solar 3m diamond grade sign solar Highway traffic signs

Share on (60660460075):


Price:

Quantity:


Product Overview

Description


Product Description
\t
Housing Material
\t
2.0mm thickness Aluminum board
\t
Standard
\t
GB14887-2003 China, can be customized
\t
Solar panel
\t
18V, 10W single crystalline silicon solar cell, battery life≥15 years
\t
Battery
\t
12V, 6AH rechargeable lithium battery(optional)
\t
Shape&size
\t
circle/triangle/rectangle/Customized
\t
Led Color
\t
Yellow/white/red
\t
Certification
\t
CE/IOS9001
\t
Reflective film
\t
USA 3M High reflective film/China domestic reflective sheeting/Engineering grade(customized)
\t
Normal life of led
\t
≥100000 hours
\t
Rate of system
\t
≤6W
\t
Work mode
\t
24hrs/day or light control (by switch)
\t
Strobe mode
\t
Strobe
\t
Flash frequency
\t
2Hz, 30times/min, can be customized
\t
Duty Ratio
\t
1/3
\t
Visual range
\t
≥800m (at night)
\t
Operating Temperature
\t
-25℃~55℃
\t
Operating Humidity
\t
≤95%
\t
Working time
\t
can work over 120 hours or 6 rainy days after fully charged
\t
IP Grade
\t
IP54
Feature and Usage

Advantage:

1.Simple to install. No need external power, no need wiring.

2.Energy saving. Low-power, solar cell, low cost

3.Environmental. No harmful substance, no pollutant.

4.Sturdy and durable. PC & Aluminum Cover, shock resistance, anti-aging, anti-corrosion

5.Stable performance. Use America ATMEL single ship to protect circuit

6.Good warning function. LED chips imported from Taiwan to achieve high quality warning.

Smart controller:

1.Automatic identification the 12V or 24V system
2.Defense of the charge protection. prevent electricity of battery to solar panel Overcharge protection. prevent solar panel to overcharge battery
3.Over discharge protection. prevent a over discharge with the battery
4.Overload protection. it will turn off by itself when the electricity reach a 1.2 times of normal, and then work again after 1~2 min
5.Temperature correction. it will modify the charge and discharge when there is a change of the temperature the battery
6.Light control. it will turn on load output at night and turn off load output at day all by itself(can be control by switch
7.Time control. base on light control, it can be set to turn on or turn off load output at different times
8.Other protection. lightning protection, prevent the reverse connection etc

Detailed Images
Releated Proudcts
Packing & Delivery



Our Company

About XINAGXU.

Group summary
Hunan Xiangxu Traffic & Lighting Hi-Tech Co.,Ltd is a professional company which are specialized in all kinds of road safety equipment, such as Traffic Signs, Solar LED Traffic Lights,Solar LED Traffic Signs,Road Studs,Reflectors, Road Barriers, Traffic Cones, ect.

&D team.

We are distributor of 3M reflective film in Hunan,our Solar LED traffic lights have got ISO9001 & CE certificate. MCU imported from USA to control flashing,3M reflective film as traditional traffic signs,ultra-high brightness LED chips imported from Taiwan to achieve high quality and new technology, it lights brightly not glare ,in daytime it reflects like regular signs at night.

We get the CE, ISO9001certification,"Hunan trustworthy enterprise", and lots of national patent. Our products can meet all requirement and test in America, Europe and all over the world. We promise to supply a high quality products with best service,OEM and ODM orders are welcomed.
