taiheng KCD4 6pin illuminated rocker switch wiring diagram

1. More than 10 years of experience 2. Various kinds of specifications can be customized. 3. Better cost control: Relatively cheap labor and strict quality control 4. Shorter lead time

Product details

Product type	electric rocker switch
Function	ON OFF, ON ON, ON OFF ON
Certificate	CQC. Rohs. CE
Lamp color	Red,Yellow, Blue, Orange
Material	PA66/PC
Housing color	Black, White, Gary, Red,Yellow
Rating	6A 250VAC / 10A 125VAC;16A 250VAC / 20A 125VAC
Led color	Red, Green, Yellow, Orange
Pins	2.,34,6
Life	≥10,000 cycles
Product Keywords	4 pin rocker switch wiring diagram,3 way rocker switch wiring,3 way rocker switch automotive

Features:

1) We have CE,RoHS,CQC for rocker switch.

2) Switch electrical lifetime above 10,000 cycles.

3) R & D team for Automation, mould & new product.

4) Automation systems.

5) Mould developing systerms.

6) New item developing according to your samples or drawings.

Quality assurance:

IQC, IPQC, PQC, OQC. Inspect for supplied material, production process and final product, including withstand voltage, insulating resistance, conductor, dimension, external appearance, etc. All elated raw materials are inspected as Rohs requires.

KCD4-201...

KCD4-201

4 pin rocker switch wiring diagram

Product Specifications

Specification of Rocker Switch
Rating		6A/250V AC, 10A/125V AC; 16A/250V AC, 20A/125V AC
Rated Load		2/8A 250V AC
Contact Resistance		≤50MΩ
Dielectric Intensity		≥1500V AC/min
Withstand Voltage		1500V AC/min
Temperature		-25~85°C
Insulation Resistance		≥100MΩ
Life		≥10,000 cycles
Pins		2/3/4/6
Function		ON-OFF/ON-ON/ON-OFF-ON
Illumniated		220V Neon Lamp
APPROVALS
CE	CQC	Rohs

Detailed Images

Part	Material
Base Plastic	Nylon
Button Plastic	PA66/ PC
Terminal	Brass(tin plated)
Contact	Compound silver/ Copper
Spring	Tungsten steel
Waterproof Cap	PVC ( If you required)
Mount	Snap in
Application: Small household products, communication equipment, energy generator, electric tools, table lamp, electric motor, electric motor car, electric toy, UPS, medical facilities, socket, etc

Terminal Type
A	4.8*0.8	G	6.3*0.8	M	2.5*0.5
B	4.8*0.8	H	6*0.8	N	5.6*0.5
C	3*0.8	I	3.8*0.8	P	2.8*0.5
D	PC	J	2.7*0.5
E	PC	K	6.3*0.8
F	6.3*0.8	L

Hot Selling Products

4 pin rocker switch wiring diagram

Yueqing Anhe Electronics Co.,Ltd.

Established in 2003, we are engaged in producing 12 categories and about 2,000 models of rocker switches,push button switches, toggle switches, micro switches, key switches,tact switches,slide switches and etc. Most of our products have passed safety certifications as CE, CQC. And lots of our products are made with RoHS compliant materials.
