Product Overview

Description


Product Description

fiber cement board production line adopts the technology of double-drive double-roller extruding,

and the product is formed once after sizing, material feeding, spreading no-woven cloth,

compounding and repressing. fireproof mgo board production line runs stably with high automatic

degree,  the specification of its product can be adjusted arbitrarily.

production line features
\t
Advantages
\t
Number
\t
Item
\t
Content
\t
1
\t
Low cost
\t
Low labour and raw materials costs
\t
2
\t
Long life
\t
Up to 30 years
\t
3
\t
Recycling use
\t
Reused for more than 8 times
\t
4
\t
Environment protection
\t
Environment-friendly raw materials used
\t
5
\t
Flexible layout
\t
adjusted according to your requirement
Equipment components

This  automatic mgo board production line in China is made up of two parts, Board making machine line and Board four-sides cutting machine Line

Board Making machine Line

\t
NO.
\t
name
\t
Function
\t
Size (mm)
\t
Power(KW)
\t
Quantity(set)
\t
1
\t
Slurry mixer
\t
Mixing cement mortar of up and own materials
\t
2300×820×820
\t
3
\t
2
\t
2
\t
Main mixer
\t
Mixing middle materials
\t
2800×1500×1300
\t
18.5
\t
2
\t
3
\t
Crusher
\t
Crush and collection material after cutting
\t
1960×880×1070
\t
11
\t
1
\t
4
\t
Duplex units feed in mould board
\t
Automatic feed-in mould board on the main formed units, no need by manual, can reduce labor, improve work speed.
\t
4800×3100×2800
\t
1.5
\t
1
\t
5
\t
Main formed units
\t
It includes all of device of automatic feed-in cement mortar, fiber cloth, spreading, one-time forming and etc.
\t
29000×1800×1500
\t
11.5
\t
1
\t
6
\t
oil brusher
\t
It can adhibit the PVC paper on the mould board by automatic. (Or brush the oil on the mould board)
\t
2700×1600×800
\t
1.1
\t
1
\t
7
\t
Automatic tracking cutting device
\t
It can cut the product on production line when it’s wet, and it will not hurt the product and mould board, reduce the labor, low labor intensity .
\t
4500×2000×1450
\t
2.45
\t
1
\t
8
\t
Hydraulic lifter of receiving board system
\t
It can load the formed board on the form rack, reduce labor, reduce hurting the board when by manual, and improve automatic.
\t
2700×3800×1700
\t
9.6
\t
1
\t
9
\t
PLC Control system
\t
Control the production line automatic.
\t
750×500×1800
\t

\t
1
conditions

The production line is composed of board-making machine,glue-spreading and veneering-drying machine and glazing machine.according to the production and the automatic degree, this production line is divided into 6 models and three specifications ,such as large ,middle and small specification.

The production line for mgo board has :production workshop ,finished product workshop and raw

material warehouse . workshop:100---1000m2,worker:3---6person,water:ordinary water

electricity:1.1—10KW(according to different scale)

project features



1. The source of the production raw materials is widely with no regional restriction. The product

is made of sand, cement,fiber glass mesh, on-woven fabrics and other fillers. The board is formed one-time by the machine.  It is easy operation,low production cost, small investment

and fast effectiveness.

2. Theproduction line has high automatic degree, simple production technology, low labor intensity and production line is no noise and three wastes (waste water, waste gas and waste residue) during production.


3. Low production energy consumption. With the influence of chemical reaction, it can meet the requirements about production technology without high temperature and high pressure.


4.It can produce according to different customers' request like size (length* width*thickness) , material .

product model


1.Thickness: 2-24mm
2. Width: 600mm-1300mm
3. Length: 2400mm-3000mm
4. Capacity :200 -----2500 sheets per day 8 hours .
5. Configuration :customization

application
Packing & Delivery
Our Service
\t
1. Full life-cycle value services:
\t
Our company provides latest building materials/Magnesium oxide board production machine/Siemens PLC control automatic Mgo board production line, cost accounting, installation and operation, equipment maintenance and the whole life cycle technical all support.
\t
2. All-around technical service:
\t
We provide technical formula for clients, to help clients to occupy the leading position in the market.
\t
3. Complete data specification:
\t
Provide production line equipment technical data and instructions, and provide the Mgo board production line formula.
\t
4. Quality commitment:
\t
Our company regards product quality as the lives of enterprises, the main components and wearing parts are made of high quality.
\t
5. Trade service:
\t
We can help the customer to do the consignment and the relevant procedure for import and export.
