3D Dental Imaging , The Most Comprehensive Smart3D CBCT for the Entire Maxillofacial Region

Product Overview

Description

Developed and manufactured by LargeV independently and all related intellectual property rights are owned by LargeV.



Highlights & Advantages:



Flexible FOV (5×5,8X8,15×8cm optional);

Patent anti-collision indicating device;

Zero dose presentation mode to relax;

Full/half width Ceph mode with low dose;

The image resolution as high as 2.0 lp/mm;

Voxel size from 0.05-0.25mm

0.5mm minifocus X-ray tube for superior image quality;



TrueMAR correction module for metal artifact removal

6 laser beam helping accurate positioning

Multiple scan modes just one-click setting

Multifunctional software & comprehensive network







Technical Specifications
X-ray Tube Voltage	60-100kV
X-ray Tube Current	2-10mA
Max Exposure Power	600W
CT Sensor Type	CsI+CMOS Flat Panel Detector
CT Field of View            (D * H)	15cm x 8cm or 12cm x 8cm 8cm x 8cm 5cm x 5cm
CT Voxel Size	0.25mm 0.125mm 0.1mm 0.075mm
CT Spatial Resolution	2.0 lp/mm
CT Scan Time	15s
CT Exposure Time	13s
CT Reconstruction Time	15s~40s
Pan Sensor Type	CsI+CMOS Flat Panel Detector
Pan Sensor Pixel Size	0.1mm
Pan Exposure Time	6s~11s
Ceph Sensor Type	Csl+CCD TDI Detector
Ceph Sensor Pixel Size	27μm
Ceph Exposure Time	8s~13s
Focal Spot Size	0.5(IEC336)
Weight	With Ceph function: 335kg Without Ceph function: 285kg
Power Requirements	AC220V±10%, 50Hz, 2000VA
Outer Dimensions	With Ceph function: 1978mm × 1526mm × 1693~2393mm Without Ceph function: 1100mm × 1526mm × 1693~2393mm
Room Requirements	With Ceph function: 2.5m × 2.1m × 2.5m Without Ceph function: 1.6m × 2.1m × 2.5m
