100% Non asbestos fiber cement board machine line/ production line

Product Overview

Description

100% Non-asbestos fiber cement board machine

line/ production line



Product Description

The production line adopts the technology of double-drive double-roller extruding, and the product is formed

once after sizing, material feeding, spreading no-woven cloth, compounding and repressing. fireproof

mgo board production line runs stably with high automatic degree,  the specification of its product can

be adjusted arbitrarily.



Technology features

Advantages
Number	Item	Content
1	Low cost	Low labour and raw materials costs
2	Long life	Up to 30 years
3	Recycling use	Reused for more than 8 times
4	Environment protection	Environment-friendly raw materials used
5	Flexible layout	adjusted according to your requirement



Equipment components

This  automatic mgo board production line in China is made up of two parts, Board making machine line and Board four-sides cutting machine Line



conditions

The production line is composed of board-making machine,glue-spreading and veneering-drying machine and

glazing machine.according to the production and the automatic degree, this production line is divided into 6

models and three specifications ,such as large ,middle and small specification.The production line for mgo board

has :production workshop ,finished product workshop and raw material warehouse . workshop:100---1000m2,

worker:3---6person,water:ordinary water,electricity:1.1—10KW(according to different scale)

product model

1. Thickness: 2-24mm
2. Width: 600mm-1300mm
3. Length: 2400mm-3000mm
4. Capacity :200 -----2500 sheets per day 8 hours .
5. Configuration :customization



frequency	pressure	equipment	rooms	capacity
50HZ	380V	1.7million M2	12M*80M/9M*40M	10KW-15KW



Item	Size	Thickness	weight
1	1220*2440mm	3mm	10kg
2	1220*2440mm	4mm	14kg
3	1220*2440mm	6mm	18kg
4	1220*2440mm	8mm	24k
5	1220*2440mm	10mm	28.5kg
6	1220*2440mm	12mm	34kg





raw materials





Our service

1)Fully life-cycle value services

Our company provides mgo board production line design ,cost accounting,installation and operation,

equipment maintenance and the whole life cycle techincal support.



2) complete data specification

Provide production line equipment technical data and instructions,and provide the mgo board production

line formula.



3) quality commitment

The company regards product quality as the lives of enterprise,the main components and wearing parts

are made of high quality wear-resistant materials and advanced processing technology,so that the

equipment endurable and wear resisting ,wearing parts warranty for one year.



4) Trade service

We can help the customer to do the consignment and the relevant procedure for import and export.
