plastic material vacuum auto hopper loader
- Category: Plastic Loader >>>
- Supplier: Guangdong Gainwal Automation Technology Co. Ltd.
Share on (60665165588):
Product Overview
Description
Product Description
Product Description:
GAL-UG series separate-vacuum hopper loaders feature more attractive appearance, better performance, Besides that, it can also realize the One-to-Two, One-to-Three, and One-to-Four way of conveying materials to different molding or hoppers to greatly lower the cost.
Feature:
1. Stainless hopper receiver ensure on contamination.
2. Motor overload protector ensure long motor lifespan.
3. Alarm for overload and lack of material.
4. It consists of a cyclone dust separator a dust collective bin to effectively reduce the load of filter.
5. Equipped with warning lamp and buzzer.
6. All main units have vacuum breaking valve to protector the blower.
Model GAL- | 300G | 300E | 400G | 700G | 800G | 900G2 | 3HP-U | 5HP-U | 7.5HP-U | 10HP-U |
Motor Type | Carbon brush | Carbon brush | Inductive | Carbon brush | Inductive | Inductive | Inductive | Inductive | Inductive | Inductive |
Motor Power (KW) | 1.1 (1Φ) | 1.1 (1Φ) | 0.75 (3Φ) | 1.1 (1Φ) | 1.1 (3Φ) | 1.5 | 2.2 | 4 | 5.5 | 7.5 |
Conveying Capacity | 200 | 200 | 300 | 200 | 300 | 500 | 750 | 900 | 1100 | 1500 |
Hopper Volume (L) | 6 | 6 | 6 | 6 | 6 | 12 | 24 | 24 | 36 | 36 |
Dia. Of Material Pipe | 1.5" | 1.5" | 1.5" | 1.5" | 1.5" | 1.5" | 1.5" | 2" | 2" | 2" |
Dimensions of Main Unit | ||||||||||
H(mm) | 590 | 650 | 660 | 590 | 660 | 740 | 1380 | 1380 | 1830 | 1830 |
W(mm) | 340 | 340 | 370 | 300 | 370 | 390 | 490 | 490 | 585 | 585 |
D(mm) | 340 | 340 | 450 | 390 | 420 | 670 | 590 | 590 | 675 | 675 |
Weight(kg) | 13 | 16 | 25 | 30 | 44 | 57 | 73 | 80 | 150 | 160 |
