Factory Price Security Checking 5030C X Ray Baggage Scanner for Hotel
- Category: >>>
- Supplier: Shenzhen Haimingwei Safety Co. Ltd.
Share on (60667048115):
Product Overview
Description
HW5030C X Ray Baggage Scanner
Product Description
General Specification
Tunnel Size | 500(W)*300(H)mm |
Conveyor Speed | 0.22m/s |
Conveyor Max Load | 150kg |
Wire Resolution | 32AWG to 40AWG |
Spatial resolution | Horizontal:1.3 or 1.0mm; vertical: 1.3 or 1.0mm |
Penetration | 30 to 40mm Steel |
Film Safety | Guarantee ISO1600 Film |
X-ray Leakage | <1 μSv/h (at a distance of 5cm from external housing) |
Pass rate | 720 bags per hour |
Installation Data
Operation temperature/Humidity | 0℃-45℃/20%-95%(non-condensing) |
Storage Temperature/Humidity | -20℃-60℃/20%-95%(non-condensing) |
Operation Power | 220VAC(±10%)50±3Hz |
Power Consumption | 1.0 KW (max), 0.3KW(working) |
Noise | <65db |
X-ray Generator
Beam direction | Diagonal |
Generate angle | 80 degree |
Anode Voltage | 140Kv or (100Kv to 160Kv adjustable) |
Anode power | 0.4 to 0.5mA |
Cooling / Duty Cycle | Oil Cooling /100% |
Image System
X-ray Sensor | L-Shaped Photodiode Array (multi-energetic), 12bit Deep |
Monitor | High Resolution Color, LCD Accord, 17 inch (19 inch optional) |
Image Processing | Edge enhancement, image strengthening, image |
Image Grey Level | 4096 |
Image Processing | 24bit for processing real time |
Image storage | Storage 60000 pictures in real time |
Zoom | max 16 Times Enlarge, Whole screen continuous observation |
Our Services
1. Any Inquiry will be replied within 24 hours.
2. Professional manufacture. Welcome to visit our wesite: www.hmwsafety.com.
3. OEM/ODM available:
1) Silk print logo on the handheld metal detector.
2) Customized the shape and color.
3) Any idea you have in mind on the metal detector, we can held you to design and put it into production.
4. Hight quality, fashion design, reasonable&competitive price, fast lead time.
5. After-sale Service:
1) All product will have been strictly Quality Checked in house before packing.
2)All product will be well packed before shipping.
3)All our product have one year warranty, and we are sure the product will be free from maintain within warranty period.
6. Fast delivery: Sample order in stock, and 7-15 days for bulk production.
7. Payment: You can pay for the order via: T/T, Western Union, Paypel&Money Gram.
8. Shipping: We have strong cooperation with DHL, TNT, UPS, FEDEX, EMS and shipping company.
You also can choose your own shipping forwarder.
