China Guangzhou High Quality Alibaba Hot Sale New Products 49" Lcd Advertising Display
Detailed Images
Product Description
Model Number
AIOTKR
Brand name
OEM, ODM
Type
TFT, Infrared, LCD Touch Screen
Application
Indoor
Panel Size
42" 49" 55" 65"
Display Colors
10 bit, 16.7M
Number of Pixels
1920x1080P
Luminance of White
450 cd/m2
Processor
RK3288, Octa core
RAM
4G, DDR3
Memory
Build-in FLASH memory 8G
Multiple Storage Media Support
Support USB 2.0/ SD/ MMC card
Video Output
HDMI Video Output
Audio Output
Dual-channel stereo audio output
Remote control
Available
Operation System
Android 4.2.0
I/O
USB2.0 x 2, RJ-45 x 1, TF card plug x 1, AV x 1, HDMI x 1, DC x 1
OS language
English (Default, multi language supported)
OS
Window7, Android
Max Resolution
1080P
Contrast Ratio
3500:1
LCD Screen
Samsung, LG, SCR
Working Life
50000h-60000h
Appearance
Classic type, Stents shapes, Chassis, Other customized
Certificate
CE FCC ROHS
Warranty
1 year
Basic functions overview
Support screen rotation, landscape and vertical display meet your different advertisement requirement.
Customizable design to provide style and ergonomic ease of operation.
LCD display projects from 8" to 108' in various brightness can be tailor-made according to your specific requirements.
We can provide the remote controlling software for you to update your advertisement by internet for digital media advertising application, Android operating system equipped with remote managing software App, once signed up, one life using. Engineers help you inplement the installing and testing of the software and 24 hours on-line help.
If you have your own interactive software, infrared touch function is optional. The window OS is also optional for pc application.
Ultra HD resolution, panel brand: Sumsung/LG/AU.
Password is used to protect the indoor digital totem from being using by stranger.
Anywhere and anytime can visit the managing backstage.
Product Data
Panel Specifications
Items
Specification
Unit
Panel Size
42 inch 49 inch 55 inch 65 inch
inch
Panel Type
TFT-LCD
/
Display Colors
8 bit, 16.7 Million
colors
Number of Pixels
1920 x 1080
pixel
Luminance of White
450 (Typ.)
cd/m2
Contrast
3500:1 (Typ.)
/
Viewing Angle
160/120 (H/V)-Fullview
degree
Aspect Ratio
16:9
/
Response Time
6.5 (Typ.)
m-sec
Life Time
60,000
hours
PC Specifications
Solution: Intel i3
Parts
Specification
Processor
Intel i3 3240 (3.4GHz, dual core)
RAM
4G DDR3 (Kingston)
Hard Disk
500G 5400rpm (Seagate)
Mother Chipset
Intel H61 chipset, Sandy Bridge
Video Chipset
Intel HD Graphics, Shared memory
Audio Chipset
Intel HD audio
I/O ports
4xUSB 2.0, 1xRJ-45, 1x3.5mm jack plug, 1xHDMI, 1xVGA, 1xDC 12V
Internet
Default: RJ-45 and Wi-Fi. Optional: 3G
Loudspeaker
2 x 8Ω/ 5W
OS
Android, Linux, Windows XP, Vista, 7/8 (32 bit) / extra cost for original version
OS Language
English (default)
Touch Performance
Touch Screen Type
Infrared
Touch Condition
Finger, touch pen or anything un-transparent
Touch Points
6 points. Optional: 4, 8, 16, 32 points
Interpolation Resolution
32767 x 32767
Response Time
≤ 20m-sec
Min Touch Diameter
5mm
Touch Accuracy
±2mm for 90% area
Platform
4mm thickness tempered glass
Appearance
Color
White (default), black and customized
Case
2mm cold-rolled sheet
Paint Process
170°~ 180°Baking finish
Application
Floor stand
Others
Power Input
AC 100 ~ 240V, 50/60 Hz
Max. Power Consumption
122KWh
Standby Power Consumption
<5KWh
IP Code
IP20
Working Temperature
0 ~ 40°
Storage Temperature
-20 ~ 55°
Working Humidity
20% ~ 80%
Storage Humidity
10% ~ 90%
Unit Package
PE film + Foam corner protector + Carton
Export Package
Export wooden packing
Accessories
Driver CD
Warranty
1 Year
Question and answer
Q1: Are you a factory or a trading company? A: We are a OEM/ODM factory.
Q2: What payment methods your company accept? A: We accept most of the payment methods,but mainly accept T/T,L/C, and Western Union.
Q3: How long is the warranty time for your products? A: Our officially promised warranty time is one whole year after delivery.
Q4: What will you do if the product be nature damange within warranty time and how about out that time? A: Well, we will give some quite simple questions to help us confirm the damaged part. Once it confirmed, the free replacement will be send. Also, we will just request a very low price for replacement part, if the product out of warranty time.
Q5: Do you give any discount? A: I'll surely try my best to help you get those by the best price and good service at the same time.
Q6: Can I customize the product I ordered? A: Abusolutely yes, customizatiion offer from customers are most welcome in our company.
