1700 electric sintering vacuum furnace
- Category: >>>
- Supplier: Zhengzhou Shibo Nonferrous Metals Products Co. Ltd.
Share on (60670860520):
Product Overview
Description
VF-1600 vacuum box furnace for heating treatment,
High temperature laboratory vacuum furnace is widely used for heating treatment of metal materials in low vacuum ,recursive ,protective atmosphere ,also can be used for heating treatment of special materials ,such as carbonization process of carbon products .The furnace chamber is ceramic fiber with excellent thermal insulation.
Specification:
Furnace valume: 300*300*300mm
Structure: Double layer steel structure with air fan cooling.
Max. temperature: 1600C
Work temperature: 1500C
Temperature control: 50 segments programable and PID auto control
Heating elements: high permance 1700C MoSi2 heating elements
Heating rate: ≤ 15C/min
Temperature accuracy: +/-1C
Max vaccum: 10Pa
Working voltage: AC380V, 50/60HZ, double phase or as your requirement.
Warranty: 1 year
Our Standard Size:
Model | Chamber size(W × H × D mm) | Max. Temperature | Working temperature |
VF-1700 | 150x150x150mm (6"x6"x6") | 1700 degree | 1600 degree |
VF-1700 | 150x150x200mm (6"x6"x8") | 1700 degree | 1600 degree |
VF-1700 | 200x200x200mm (8"x8"x8") | 1700 degree | 1600 degree |
VF-1700 | 200x200x300mm (8"x8"x12") | 1700 degree | 1600 degree |
VF-1700 | 250x250x300mm (10"x10"x12") | 1700 degree | 1600 degree |
VF-1700 | 300x300x400mm (12"x12"x16") | 1700 degree | 1600 degree |
VF-1700 | 350x350x400mm (14"x14"x16") | 1700 degree | 1600 degree |
VF-1700 | 400x400x400mm (16"x16"x16") | 1700 degree | 1600 degree |
VF-1700 | 500x500x500mm (20"x20"x20") | 1700 degree | 1600 degree |
Your special size is welcome.
