wifi gprs gsm rfid security system diy door sensor camera alarm

•  2.4inch TFT display screen,concise user interface and menu hiint design.
• Main interface status bar, date/clock indication, fairly obvious alarm host status.
• Build-in powerful performance CPU master based on 32-bit Cortex-M3 core.
• Based on uCOS-III operating the system with multitasking design, great user operation experience.
• WIFI/GSM/3G/GPRS intranet alarm system,support different alarm  channels,like APP push/SMS/voice monitoring/intranet center etc.to ensure the alarm performance stable and reliable.
• Support SMS arm/disarm and voice arm/disarm
• Support up to 100 learning/storage location for remote control,RFID cards and wireless detector.
• Support many defense zones,such as gate,sos,bedroom,window ,balcony,perimeter,smoke,gas,carbon monoxide,water leaking,etc.
• Support the main power malfunction,backup power shortage,tamper alarm and other extended alarm.
• support entry/exit zone,indoor zone,perimeter zone,24-hour zone..etc.
• up to 5 groups preset alarm phone numbers,SMS on/off and dial on/off can be set respectively
• support external wireless siren.
• support timing arm and disarm.
• can store  and inquire daily operation recodes and alarm records.
• GSM network clock synchronization,to ensure accurate clock,and support country time zone settin
• support multi-language menu display,voice prompts and alarm SMS setting.
• can record 20 seconds voice message and alarm voice.
• Telephone function,support 5 groups re-dial number.
• User-friendly APP operation experience and user interface.
• Push arm/disarm message to APP
• support app remote arm/disarm ,para,eter setting and accessory management.
• Online GPRS to obtain equipment status,automatic alarm when offline.
• Reserved remote GPRS TCP/UDP protocol channel,compatible with multiple alarm center networking protocol to facilitate network alarm.

 Input voltage: DC5V(micro USB jack)

 Working current: <120mA

 Standby current: <80mA

 Siren output: <500mA

wireless frequency:433MHz

GSM bands:850/900/1800/1900MHz

 WIFI Standard:IEEE802.11b/g/n wireless standard

Back-up battery: 500MA/H, DC3.7V lithium battery.

Working temperature,  0~ 55ºC;

relative humidity: <80% RH(No freezing)

Product dimension:185*125*14.7mm(L/H/T)

1. Q: Why to choose us?

      A: a. Professional experience and ability to accept and fulfill ODM/OEM orders.

             b. Answer your enquiries, questions and emails in 24 hours

            c. Direct control on material, testing, quality, lead time ect.

            d. Flexible Payment terms ranged at different quantity

            e. One year warranty life for all detectors sold out from us.

2. Q: What is the advantage of your products?

     A: We are professional manufacturer in this field with lots of years R&D and market research experience, we can provide competitive price and high quality products for you.

3. Q: Can you help us design or monify the products as we requestion?

     A: We have R&D capability and professional&efficient team, customized service and OEM/ODM are welcomed. We will try our best to satisfy you.

4. Q: What are the terms of Payments?

     A: L/C, T/T, Western Union, Paypal, Escrow and Cash

1.Any inquiries will be replied within 24hours on workday

2.Professional manuafacurer and wholesaler for 6years.

3.OEM &ODM are available:

4.We can help you to design and put it into production about your idear

5.High quality, fashion design, reasonable&competitive price, fast lead time

6.After-sale service:

All products will have been strictly Quality checked in workshop before packing

All products will be well packed before shipping.

All our products have 12 mouths warranty, and we are sure our products will be free from maintenance

7.Fast delivery:

Sample order in stock; 10~100pcs: 2~3 days; 3~7 days for bulk order

8.Payment:

You can pay for the order via: T/T , Western Union and MoneyGram
