High Quality Electric Reach Stacker with Good Price RS1055

Share on (60672363919):


Price:RUB 766,753.00 - RUB 920,103.60

Quantity:


Product Overview

Description

Company Profile

Taizhou Jetstar Machinery Equipment Co., Ltd. is a professional manufacturer engaged into designing and producing logistic and industrial equipments for more than 15 years. Our supply scope covers pallet truck, pallet stacker, electric forklift, drum lifter and scissor lift.

Our team are always ready to provide not only quality products but also perfect customer service.

Brief Introdution

1. Because of CURTIS electronic control, so we have multiple automatic protection system controllers.

2. EPS swerve can reduce 20% of the energy consumption. It is precise, flexible, and convenient to operate. At the same time, it can reduce driver fatigue, boost productivity.

3. Moved forward type electric stacker is suitable for large tonnage, high hoisting cargo storage applications,applying to a variety of trays, and has the characteristics of moving forward for overall door frame. Furthermore, it has small turning radius and can neglect obstacles from the bottom of the shelf. So it is suitable for narrow channel.

4. During the operation of decline, the pallet fork is kept in safe when hoisting control lever is in decline position. Especially when pallet fork drop to 10 cm above the ground, then speed will slow down automatically. It can effectively protect the goods from damage due to vibration. When the pallet fork goes to the top, buffering system can reduce the vibration of the door frame. So it is comfortable for operator.

5. Stable start can be realized by small space and strong AC motor. No need of complex acceleration operation, small-space maintenance cost is greatly reduced without carbon brush and contactor.

Product Description

High Quality Electric Reach Stacker with Good Price RS1055 Application

High Quality Electric Reach Stacker with Good Price RS1055 is mainly used in pallet stacking and short distance transportation at plants, warehouse and logistics systems etc. This machine is an electric forklift truck with steering bar drive and is perfect for storing and transporting loads on perfectly even surfaces. An identification plate can be found on the chassis indicating the lifting capacity that must never be exceeded both for the safety of the personnel and not to damage the vehicle. Please observe the safety, use and maintenance regulations to the letter. Any mounting of extra equipment on this machine must be authorized by the manufacturers.

SPECIFICATIONS OF HiGH QUALITY ELECTRIC REACH STACKER WITH GOOD PRICE RS1055
                                                                                                                                                                                                                               General
Manufacturer
Jetstar
Model
RS1055
Drive
Electric (Battery)
Operator Type
Standing
Rated Capacity/ Rated Load
1000kg
Load Center Distance
600mm
                                                                                                                                                                                                                                                                                                   Characteristics
Max. Fork Height
5500mm
Lower Fork Height
90mm
Fork Length
1070mm
Fork Individual Width
100mm
Fork Height
70mm
Fork Overall Width
570mm
Motors Travelling
1.5kw/24v
Motors Lifting
2.2kw/24v
                                                                                                                 Performance
Travelling Speed with/without load
4/6 km/h
Lifting Speed with/without load
80/130 mm/s
Lowering Speed with/without load
110/90 mm/s
Gradient
5/8 %`
                                                                                                           Chassis
Overall Length
2150mm
Overall Width
1000mm
Mast Extended Height
5950mm
Mast Lowered Height
2525mm
                                                        Wheel
Front Wheel
4*Φ80*70
Rear Wheel
Φ156*50
Driving Wheel
Φ250*100
Battery
Battery (Voltage/Capacity)
24 V/280Ah
Controller
Controller System
Curtis
Weight
Net Weight
2050kg

Main Features

1) Top quality electronic control system from Curtis;
2) Drive unit with electromagnetic brake;
3) Compact design for easy operation in narrow aisle;
4) Conforms to EN1726, EN60204 and EN ISO 12100;

Certifications
Our Service

Pre-Sales Service

* Inquiry and consulting support.

* Sample testing support.

* View our Factory.

After-Sales Service

* Training how to install the machine, training how to use the machine.

* Engineers available to service machinery overseas.
