China supplier automatic door operator sliding door kit


| Technicial data | ||
Rang of the Door | Single-leaf | Double-leaf |
Door leaf max weight | 150kg/leaf | |
Power Supply | AC 110v-260v, 50-60 Hz | |
Opening Speed | 100-500mm/s (adjustable) | |
Closing Speed | 100-500mm/s (adjustable) | |
Creep speed | 30-100mm/s (adjustable) | |
Hold-open time | 1-10s (adjustable) | |
Hold-Close Force | 70N<f<250N
| |
Manual Pushing Force | <100N | |
Rated power | 60W | |
ambient temperature | -25~+50 C | |



Advantages:
1 Wide voltage range(AC80-260v),low power consumption when at work(180W), energy saving when at leisure(3w)
2 Intelligent design, easy to install and adjust.
3 Digital programs, running parameters can be revised easily.
4 Specially designed noise-reduction track rail produces noise greatly, ensures the rollers run smoothly.
5 Advanced brushless DC motor and the worm-reduction gear are integrated together, which has advantages such as higher efficiency, larger torque and longer life span, no need for mechanical lock.
6 Different triggering modes are available, such as fire warning, safety beam sensor, handle button, etc.
7 The motor can lock automatically if there is no triggering signal. The powerful closing force keeps the door shut fast. (with power on)
8 1 millions times of tests passed.
9 CE , SGS, ISO9000:2008 certificated.
