Electro tricycle Lead Acid Battery PE AGM Battery Separator
- Category: >>>
- Supplier: Jiangsu Magicpower Power Supply Equipments & Technology Co. Ltd.
Share on (60673067728):
Product Overview
Description
China Wholesale Electro-tricycle Lead Acid Battery PE AGM Battery Separator
Product Description
Wholesale Electro-tricycle Lead Acid Battery PE AGM Battery Separator would enhance the separator’s oxidation resistance by separate the separator by plate. The flat glass mat also will prevent the active material from shedding, and extend battery life.
It is a composite battery material specially engineered for extra heat and oxidation resistance as such, it may be termed as “Tropicalised Separator” highly suited for high temperature abusive conditions. The unique glass fiber -polymer integration affords additional elements of plate protection and extended battery life.
The product is offered either with glass tissue or with special cast ribs or with both. The thickness range varies from 0.3mm (only base web) to 4.5mm including rib and glass mat. Furthermore, the ribs come in both straight and sinusoidal shape. The cast rib process permits a high degree of product customization for specific battery applications such as automotive and industrial including gel batteries.
MAGICPOWER PE SEPARATORS’ unique formulation results in increased puncture strength, low electrical resistance, high oxidation resistance and low water loss. It can also be used in SLI applications.
Available in straight, diagonal and s-rib profiles, MAGICPOWER PE SEPARATORS offer advanced technology and unmatched customization to exceed your requirements in the toughest applications.
MAGICPOWER PE SEPARATORS can be laminated with glass fiber mat that extends battery life under arduous operating conditions such as high ambient temperatures and severe vibration.
China Wholesale Electro-tricycle Lead Acid Battery PE AGM Battery Separator Technical Data | ||||
Item | Unit | Parameters | ||
PE+GM 0.300 | PE+GM 0.600 | PE+GM 0.800 | ||
O/A | mm | Standard±0.100 | Standard±0.100 | Standard±0.100 |
Laminate Inset from Separator Edge | mm | 8.0±2.0 | 8.0±2.0 | 8.0±2.0 |
Electrical Resistance | Ω.sq dm | ≤0.0015 | ≤0.0015 | ≤0.0015 |
Porosity | % | ≥55 | ≥55 | ≥55 |
Moisture Content | % | ≤4.0 | ≤4.0 | ≤4.0 |
Dimension Stability | % | ≤1.0 | ≤1.0 | ≤1.0 |
Acid Weight Loss | % | ≤4.0 | ≤4.0 | ≤4.0 |
Fe Content | % | ≤0.010 | ≤0.010 | ≤0. 0.010 |
Cl Content | % | ≤0.030 | ≤0.030 | ≤0.030 |
Reducing Substance | Ml/g | ≤10 | ≤10 | ≤10 |
Packaging & Shipping
- Packing: Plastic bag or carton for customer's choice
- Port of Shipping: Shanghai
Company Information
Welcome to Jiangsu Magic Power!
Jiangsu Magic Power Power Supply Equipments & Technology Co., Ltd. is an acknowledged leading manufacturer in lead-acid storage battery separator industry in China. We mainly provide PE & PP battery separators and other related products for our customers both in China and abroad. We have an affiliated company Zhenjiang Magic Power Import & Export Trading Co., ltd, providing import & export services for our customers.
Our company started research & development from 2010 in cooperation with some experienced experts in this industry and technical university. We worked on the main raw material of the product polyethylene, SiO2, extending oil, and key auxiliaries affecting product quality; we optimized the process of squeezing out, shaping, oil controlling, drying and surface activating. Our product, which is totally equal to imported product in quality and achieved the international advanced level, has passed the tests of the industrial official authorities and got good feedbacks from our customers for trial use in February 2011.
We can also provide you the complete advanced PE production lines, and electric bicycle accessories such as brake levers, multifunctional switches, wing mirrors, etc., and power supply equipments such as bus bars, cable trays, and low voltage switchgears.
We are committed to providing more than just quality products for our customers, as well as offering a range of value added services including technical service and timely response to customers. We are cooperating with you not only to meet your highest expectations, but also to help you continually develop new markets. We sincerely hope to cooperate with customers from all over the world. If you are interested in our products, please don't hesitate to contact us!
