Jiexiang HD 1080P 2.5 2.7GHZ 400W Digital MMDS Transmitter
- Category: >>>
- Supplier: Chengdu Jiexiang Technology Company Ltd.
Share on (60673839877):
Product Overview
Description
Jiexiang HD 1080P 2.5-2.7GHZ 400W Digital MMDS Transmitter
Skype: live:jiexiang02 to contact Jaylyn
| Model | JX-1740A | |
| RF Output Power(P-P) | 400W | |
| Shoulder Ratio(dBc) | ≥40 | 64QAM |
| ≥30 | QPSK | |
| RF Output Frequency | 470~860MHz(frequency band carrier signal takes could be set arbitrarily) | |
| Max Bandwidth: within 80MHZ | ||
| RF Output Interface | 50Ω/N connector | |
| Return Loss: 20dB | ||
| RF Frequency Response | BW: 80MHz | |
| Passband Fluctuation: ≤2.0dB | ||
| Any Within 10MHz: ≤1.0dB | ||
| Group Delay Characteristics | ≤40nsec | |
| Local Frequency | 2033MHz(or specified by user) | |
| Stability: 1×10-6 | ||
| Local Ocillator Phase Noise | NΦ≤-100dBc/Hz@10KHz | |
| IF Input Level | -25~-10dBm | |
| IF Input Frequency | 467~667MHz(or specified by user) | |
| IF Input Interface | 75Ω/F connector | |
| Return Loss: 15dB | ||
| In-band Spur Restraint | -60dBc(relative signal level) | |
| Automatic Level Control | 20dB | |
| Environmental Conditions | Working Temperature Range: -20°C~+45°C | |
| Humidity: no condensation | ||
| Relative Humidity: 0~95% nonsaturation | ||
| Working Voltage | AC 220V±10%,50/60Hz | |
| Packaged Size (L*W*H) |
87*59*46cm | |
| Packaged Weight(Kg) | About65kg | |
