Product Overview

Description

Product Description

Mars USB3.0 Cameras

Mars series USB industrial cameras, with USB3.0 high-speed data transmission bus, have a extremely high frame rate on the condition of high image quality and stability. The cameras follow USB3.0 data bus standard; support GenICam , USB3 Vision®; can seamlessly connect with other third-party platform . Mars series USB industrial cameras support Plug-and-Play, also could work stably in a variety of harsh environment. It’s distinguished itself by high reliability and high cost-performance.

Features

- USB 3.0 backwards compatible with USB2.0, and provides 5Gpbs bandwidth with power supply.
- Mechanical Dimension:20*29*29 mm.
- 128MB on-board frame buffer for image data transmission
- support software.
- Support API trigger / External trigger / Free Run mode and other trigger mode.
- Support sharpness, noise reduction, gamma correction, LUT and other ISP functions.
- Supports several image data formats output, ROI, binning, decimation, mirror etc.
- Conforms to USB3 Vision protocol and GenICam standard.

Model Table
Model
Max Resolution
Sensor Type
Format
Mars640-815UM
Mars640-815UC
640×480
PYTHON 300
1/4''
Mars800-545UM
Mars800-545UC
800×600
PYTHON 500
1/3.6''
Mars1300-210UM
Mars1300-210UC
1280×1024
PYTHON 1300
1/2''
Mars2000–150UM
Mars2000–150UC
1920 × 1200
PYTHON 2000
2/3''
Mars5000–60UM
Mars5000–60UC
2592 × 2048
PYTHON 5000
1''
Pixel Size(μm)
4.8×4.8
Color Catagory
Mono/Color
Data Bits
8bit / 10bit
Exposure Mode
Global Shutter
Output Interface
USB3.0
Exposure Time
16μs~1s
SNR
>38dB
Lens Mount
Standard C-Mount
Power Input
USB
Power Consumption
3.5W
Hardware Control
I/O input (external trigger), I/O output, Opto-couplers Isolation
Programmable Control
Image Resolution, RGB gain, Exposure Time, Contrast, Gamma Chart, Image Rollover, Raw,LUT,Black Level Correction
Operating System
Support Windows 2000/ XP/7/8/ 10; Support 32-bit and 64-bit Arm/Linux
Operating Temperature
-30~80℃(Storage), -30~50℃(Working)
Dimension
29.0 mm × 29.0 mm × 29.0 mm  (60g)
Product Dimension
Our Company

As one high-tech enterprise Hangzhou Contrastech Co., Ltd. specializes in providing professional machine vision software, hardware and equipments. Contrastech has been researching and developing machine vision applications, and the major products include industrial camera, scientific standard camera, high definition frame grabber card, industrial FA lens, telecentric lens, machine vision lights and image processing software. The Engineering Dept. of Contrastech have lots of mature and successful machine vision solutions based on automatic industrial inspection, high precision measuring and module distinguishing.
