Cheap price electronic mullen burst strength tester bursting testing machine
- Category: >>>
- Supplier: Hangzhou Zhibang Automation Technology Co. Ltd.
Share on (60674905206):
Product Overview
Description
Product Description
Cheap price electronic mullen burst strength tester
Introduction
the basic instrument for testing the anti-bursting degree of paper and cardboard. It conforms to the standards of ISO2758 Paper-Determination of bursting strength, ISO2759 Board-Determination of bursting strength and GB1539 (method for testing cardboard bursting strength).
It uses high precision sensors. With data processing, the data can be directly obtained , and can automatically reset.It has the advantage of easy operation, easy adjustment, stable performance,which make it become the essential instrument for papermaking ,packing, inspection and research.
Main Features
1Micro-computer control, use hydraulic oil as the driving force to break the specimen.
2.When the specimen is broken, it stores the maximum automatically
3.Automatic measurements, statistics, print the test results, and has data storage function
4. Micro-printer, high print speed, low failure;
5.Mechanical and electrical integration of modern design, compact structure, excellent appearance, easy maintenance
6.pneumatic sample clalmping
Main technical parameters
Item | ZB-NPY5600 | ZB-NPY1600 | |
Power | AC220V±10% 50HZ | ||
Measuring range(kPa) | 200-5600 | 50-1600 | |
Accuracy | ±0.5%F.S | ||
Compression speed(ml/min) | 170±15 | 95±5 | |
Clamp pressure(kPa) | ≥690 | ≥430 | |
Diameter of clamp | Upper clamp | 31.5±0.05 | 30.5±0.05 |
Lower clamp | 31.5±0.05 | 33.1±0.05 | |
Hydraulic oil | 85% silicon oil, 15% distilled water | ||
Film resistance(kPa) | when the bulge height is 10mm, the pressure is 170~220kpa, | when the bulge height is 9mm, the pressure is 25~35kpa | |
when the bulge height is 18mm, the pressure is 250~350kpa
| |||
Related Products
Company Information
Hangzhou Zhibang Automation Technology Co., Ltd. is a high-tech enterprise, located in Binjiang National High-Tech Industrial Development Zone, Hangzhou, Zhejiang Province.
Company philosophy: professionalism, dedication, devotion
Company tenet: quality first, consumers first
Company slogan: everything only for users
Packaging
After Sales Service
· One year warranty period. Maintenance and replacing the damaged parts are free of charge in warranty period.
· Lifetime Maintenance.
· Professional operation training.
· Spare parts and wearing parts will be provided for a long time.
· Calibration instruction service.
· Provide sample test service and lab data sharing service.
