Tuna Salmon Floating Fish Pellet Machine Making Factory From China Description:

1.According to different requirements, variety shapes of high-grade feed pellets for fish, shrimps .etc can be produced.
2.The finished pellets can keep floating for 3-15 hours without pollution to water.
3.The floating time can be controlled by the puffing degree adjustment.
4.Floating fish feed machine can make pellet from dia.1.0mm-20mm just by changing the mold.
5.Electric heating device is adopted which can improve the feed expansion rate and pellets floating time.
6.High temperature and high pressure cooking process can kill the salmonellosis and bacterial infections and also makes the pellets easily to digest.
7.The cutting device can be adjusted to make pellets of different length.
8.The wet type machine needs a boiler to make steam which can conduct steam to the conditioner and ripen the raw material in advance.

\t
Tuna Salmon Floating Fish Pellet Machine Making Factory From China  specification
\t
Model
\t
Capacity (T/H)
\t
Main motor power ( kw)
\t
Feeder Power( kw)
\t
Diameter of screw (mm)
\t
Cutter power
( kw)
\t
Dimension ( mm)
\t
Weight (kg)
\t
ASTDGP
40
( 1phase)
\t
0.03-0.04
\t
3.0*2
\t
0.4
\t
Φ40
\t
0.4
\t
1500*1400*1250
\t
280
\t
ASTDGP
40
(3 phase)
\t
0.03-0.04
\t
5.5
\t
0.4
\t
Φ40
\t
0.4
\t
1400*1030*730
\t
240
\t
ASTDGP50
\t
0.06-0.08
\t
11
\t
0.4
\t
Φ50
\t
0.4
\t
1470*1100*1250
\t
320
\t
ASTDGP60
\t
0.12-0.15
\t
15
\t
0.4
\t
φ60
\t
0.4
\t
1470*1120*1250
\t
350
\t
ASTDGP70
\t
0.18-0.25
\t
18.5
\t
0.4
\t
φ70
\t
0.4
\t
1650*1400*1300
\t
580
\t
ASTDGP80
\t
0.3-0.35
\t
22
\t
0.6
\t
φ80
\t
0.6
\t
1800*1450*1300
\t
695
\t
ASTDGP90
\t
0.4-0.45
\t
37
\t
0.6
\t
φ90
\t
0.8
\t
2100*1450*1350
\t
950
\t
ASTDGP120
\t
0.5-0.6
\t
55
\t
1.1
\t
φ120
\t
1.5
\t
2400*1950*1600
\t
1700
\t
ASTDGP135
\t
0.7-0.8
\t
75
\t
1.1
\t
φ133
\t
2.2
\t
2550*2050*1650
\t
1900
\t
ASTDGP160
\t
1.0-1.2
\t
90
\t
1.5
\t
φ155
\t
3.0
\t
3100*2650*1800
\t
3200
\t
ASTDGP200
\t
1.8-2.0
\t
132
\t
2.2
\t
φ195
\t
3.0-4.0
\t
3100*2850*1900
\t
3800
Detailed Images
\t
Steam Type Tuna Salmon Floating Fish Pellet Machine Making Factory From China Specification
\t
Model
\t
Capacity (T/H)
\t
Main motor power (kw)
\t
Feeder power( kw)
\t
Diameter of screw (mm)
\t
Cutter power
( kw)
\t
Conditioner power( kw)
\t
Dimension (mm)
\t
ASTDSP60
\t
0.18-0.2
\t
15
\t
0.4
\t
60
\t
0.4
\t
0.75
\t
1780*1250*1300
\t
ASTDSP70
\t
0.25-0.30
\t
18.5
\t
0.4
\t
70
\t
0.6
\t
1.5
\t
2460*1550*1740
\t
ASTDSP80
\t
0.35-0.40
\t
22-30
\t
1.1
\t
80
\t
0.75
\t
1.5
\t
2650*1450*1750
\t
ASTDSP90
\t
0.50-0.60
\t
37
\t
1.1
\t
90
\t
1.1
\t
2.2
\t
2600*2100*1900
\t
ASTDSP120
\t
0.70-0.80
\t
55
\t
1.1
\t
120
\t
1.5
\t
2.2
\t
3200*1950*1900
\t
ASTDSP135
\t
1.0-1.2
\t
75
\t
1.5
\t
135
\t
2.2
\t
3.0
\t
3750*1980*1800
\t
ASTDSP160
\t
1.8-2.0
\t
90
\t
2.2
\t
160
\t
2.2
\t
4.0
\t
6600*2800*2330
\t
ASTDSP200
\t
3.0-4.0
\t
132
\t
2.2
\t
200
\t
3.0
\t
5.5
\t
6600*2900*2350
Packing & Delivery

Wooden Case Packing

use plywood wooden case packing , more strong

Tuna Salmon Floating Fish Pellet Machine Making Factory From China single machine

easy operation, low cost.

\t
Name
\t
Tuna Salmon Floating Fish Pellet Machine Making Factory From China line
\t
Consist
\t
Hammer Mill
\t
Mixer
\t
Floating fish Feed Extruder
\t
Dryer
\t
Cooler
\t
Packing Machine
\t
Capacity range
\t
we have below capacitty range for your choice
100-150kg/h ;200-150kg/h;300-350kg/h
400-450kg/h;500-600kg/h;700-800kg/h
1000-1500kg/h;1800-2000kg/h;
2000-3000kg/h

Final Feed Sample


Final Feed Sample

floating time : 24 hours for fish feed, it also can make pet feed
