experienced manufacturer mixing tanks soy sauce
- Category: >>>
- Supplier: Guangzhou Beyer Machinery Equipment Company Limited [Guangdong China]Guangzhou
Share on (60676665523):
Product Overview
Description
Product Description
experienced manufacturer mixing tanks soy sauce
Use world famous brand electric components to produce high quality machine for stable quality!
Product Detail
| Voltage | 220V/380V |
| Working pressure | 0.2MPa~3.5MPa |
| Material | SUS304/SUS316L |
| Application | Liquid washing products.beverage etc... |
| function | Mixing,Heating,Cooling |
| Standard | GMP Requirement |
| Product Keywords | mixing tanks soy sauce |
Features:
1 .The all-around wall scraping mixing adopts the frequency converter for speed adjustment, so that high quality products of different processes according to customer requirements.
2 .The diversified high-speed homogenizer can powerfully mix solid and liquid raw materials and can rapidly dissolve many indissoluble materials such as AES, AESA, LSA,etc.during the liquid detergent production period.
3. The pot body is welded by imported three-layer stainless steel plate.the tank body and the pipes adopt mirror polishing, which fully conforms to GMP requirements
4. According to customer requirement, the tank can heat and cool materials the heating way including steam heating and electric heating.easy to discharge,bottom direct discharge or by transfer pump.
Technical parameters :
| Volume | Blending Power | Speed of Agitator | Power of | Speed of | Heating |
| homogenizer | homogenizer | manner | |||
| L | KW | R/MIN | KW | R/MIN | Electric |
| 200 | 1.5 | 0~65 | 3 | 3000 | or |
| 500 | 2.2 | 0~65 | 4 | 3000 | Steam |
| 1000 | 2.2~4 | 0~65 | 7.5 | 3000 | heating |
| 1500 | 4~5.5 | 0~65 | 11 | 3000 | |
| 2000 | 5.5 | 0~53 | 11 | 3000 | |
| 3000 | 7.5 | 0~53 | 15 | 1500 | |
| 5000 | 11 | 0~53 | 22 | 1500 |
Quality assurance:
1. Accept the third party check before delivery.
2.1 year warranty.
