High quality 3D printer Smoothieware control board MKS SBASE V1.3 32 bit open source Smoothieboard compatible Smoothieware

High quality 3D printer Smoothieware control board MKS SBASE V1.3 32-bit open source Smoothieboard compatible Smoothieware

Shipping list:

1pcs * MKS SBASE  V1.3

1pcs * USB

1pcs * 8G TFcard

N.W.: 0.2Kg

Overview

MKS SBASE is a latest  motherboard for 3D Printer.It is based  on ARM platform and uses  32bit 100M Cortex-MS MCU-LPC1768.

Respect to MKS SBASE V1.0 :

MKS SBASE V1.2

1.Fix temperature problem.

2.Add thermocouple Pins( can't be used with 12864lcd together).

3.Create some pins P1.22 P1.23 P2.12 P2.11 P4.28 for further developing.

4.Extend  3.3V / 5V for endstops power.

5.Preassemble   two big heatsinks. Good NewsWe improved Ethernet bug on MKS SBASE.We have changed the Crystal.We used QRA26B25.0000MFT2C2F instead of CSTCE25M0V53-R0 ,replaced CSTCE12M0V53-R0 with QRA26B12.0000MFT2C2F .

Features

1. Using 32bit 100M Cortex-M3 MCU-LPC 1768, and improve its performance highly.

2. Support highly modular open source firmware Smoothieware, easy for secondary development.

3. Support network function, then  proceed remote control via IE Explorer.

4. Using DRV8825 stepper driver which supports 32-microstep and with excellent cooling.

5. Currents of the stepper motor can be set directly, which can avoid the damage .

6. Using high quality FR-4 4 layers PCB and special design for cooling.

7. Using professional power chip, support 12V-24V DC input.

8. Good to work with LCD12864 and MKS TFT touch screen.(Can't work with OLED12864 and LCD2004 display)
