Suitable used on Dolev 800 red sensitive film, size 660mm*60m imagesetting film

Product Overview

Description

Suitable used on Dolev 800 red sensitive film,  size 660mm*60m imagesetting film

                                           ( They are widely used for offset printing   )











Offset Printing, for example: magazine printing.



*Application



RL-100E has achieved excellent performance both at He-Ne laser typesetters and red-laser diode imagesetter to get high quality image.
It's suit for offset printing.



*Main Properties



. Emulsion coated on a 0.10 mm polyester base
. Imagesetting Film RL-100E is suitable for imagesetters with laser light sources of 632.8nm, 633nm, 635nm, 650nm, 670nm and 675nm.
. Hard dots, excellent image quality
. Low fog density, transparent film at ordinary processing conditions, maximum density up to more than 4.0
. Wide exposure and developing latitude, suitable for rapid access at high temperature
. Loading the film under room light, it is convenient and fast



*Package



The package of these three kinds of room light films can be selected according to the type of machine. The films can be loaded under room light conveniently and rapidly.
1. Room light film-feeder can be used as one-time cartridge.
2. Soft flange package can be easily placed in the special cartridge of the machine.
3. Hard flange package is suitable for machine with axis of 71.9mm diameter.
   Regular diameter:  28.6mm, 50.8mm, 71.9mm
   Surface of emulsion layer: inward or outward



They are widely used for offset printing. And suitable for different imagesetter machines.



We also supply offset ps plate, ctcp plate. ctp printing plate and flexo plate.



* Films must be opened in the darkroom.
