0117500000 TS 15X5/LL 2M/ST/ZN Mounting rail, TS 15, with slot, Steel, galvanized, chromium plated, 2000 mm Din rails
- Category: >>>
- Supplier: Wuhan,Xieyuan,Automation,Equipment,Co.,Ltd.
Share on:
Product Overview
Description
0117500000 TS 15X5/LL 2M/ST/ZN Mounting rail, TS 15, with slot, Steel, galvanized, chromium-plated, 2000 mm Din rails
General ordering data
| Type | TS 15X5/LL 2M/ST/ZN |
| Order No. | 0117500000 |
| Version | Mounting rail, TS 15, with slot, Steel, galvanized, chromium-plated, 2000 mm |
| GTIN (EAN) | 4008190150662 |
| Qty. | 2 m |
Dimensions and weights
| Length | 2,000 mm |
| Length (inches) | 78.74 inch |
| Width | 15 mm |
| Width (inches) | 0.591 inch |
| Height | 5.5 mm |
| Height (inches) | 0.217 inch |
| Depth | 5.5 mm |
| Depth (inches) | 0.217 inch |
| Net weight | 140 g |
Material data
| Material | Steel |
| Surface finish | galvanized, chromium-plated |
| Colour | Silver |
System specifications
| Version | with slot |
| Mounting rail | TS 15 |
Additional technical data
| Installation advice | Direct mounting |
| Type of mounting | Screwed |
Mounting rail
| Drill-hole diameter | 4.2 mm |
| Short circuit strength corresponds to E-Cu wire | 6 mm² |
| Slit gap | 8 mm |
| Slit length | 12 mm |
| Slit width | 4.2 mm |
| Slotted drill holes | Yes |
| Solder eyelet hole diameter (D) | 4.2 mm |
| Spacing of holes, centre-to-centre | 20 mm |
| Thickness | 1 mm |
Part Number & Model
0105420000 SAKT 1/35/LT
0105520000 SAKT 1/35/LT STB25/4
0105620000 SAKT 1/35/LT STB
0105720000 SAKT 1/35/QT1
0105820000 SAKT 1/35/DU1
0105920000 SAKT 2/35/LT/STB
0106020000 SAKT 2/35/LT 4STB
0107160000 SAK 2.5/TC AL
0107260000 SAK 2.5/TC CH
0108560000 SAK 2.5 SW 1X1
0109920000 SAK 6 KRG
0110020000 SAK 10 KRG
0110060000 SAK 10
0110070000 SAK 10 KRG/BL
0110080000 SAK 10 BL
0114100000 QL 2 SAKB10
0114660000 EGT6 EG2/EN
0117500000 TS 15X5/LL 2M/ST/ZN
0117510000 TS 15X5/LL 1M/ST/ZN
0117900000 AP SAK4-10 RT
0117910000 AP SAK4-10 I
0117920000 AP SAK4-10 KRG
0117960000 AP SAK4-10
0117970000 AP SAK4-10 KRG/BL
0117980000 AP SAK4-10 BL
0119560000 RF RS 70 RE/A3/M.BEZ OR
0119660000 RF RS 70 LI/A2/O.SG OR
0119760000 ZW 5 RS OR
0119860000 ZW 15 RS OR
0119960000 ZW 30 RS OR
0120060000 ZW 45 RS OR
