Good price 64x64 rgb led matrix p2.5 led module
- Category: >>>
- Supplier: Shenzhen Longcheng Photoelectric Technology Co. Ltd.
Share on (60677965008):
Product Overview
Description
Product Description
Good price 64x64 rgb led matrix p2.5 led module
p1.25,p1.5625,p1.667,p1.875,p2 p3 p3.9 p4 p4.8 p5 p6,p8,p10 led module
Function
HD
Ultra thin and ultra light
Low attenuation,high gray level,good stability,anti-static
Entire die casting aluminum cabinet/front open service iron cabinet
| P2.5 indoor full color led display | ||
| Unit Module | Item | Parameter |
| Part No | P2.5-LC-32S | |
| Pixel pitch | 2.5mm | |
| Module size | 160mm*160mm/320*160mm | |
| Tube chip color | full color | |
| Pixel Density | 160000dots/sqm | |
| led type | SMD2121 | |
| led combination | 1R1G1B | |
| Module resolution | 64*64dots or 128*64dots | |
| main technical parameters | Scan method | 1/32s |
| refresh rate | ≥2000Hz | |
| Brightness of white balance | ≥1200cd/sqm | |
| cabinet resolution | 192mm*192mm | |
| cabinet size | 480mm*480mm | |
| Best view distance | 3m-50m | |
| Best view angle | 160°(W)*160°(H) | |
| Storage temperature | -35℃-+85℃ | |
| Working temperature | -20℃-+50℃ | |
| working voltage | AC110/220V±10% | |
| Average power consumption | ≤600W/sqm | |
| Max power consumption | ≤1200W/sqm | |
| brightness adjustment method | Brightness induction automatic adjustment | |
| MTBF | ≥5000hrs | |
| Control system | Display card | DVI graphics |
| Control method | Synchronization/Asynchronization | |
| Operation syetem | WIN98,WINXP,WIN2000,etc | |
| display sign | RF,S-Video,RGB,RGBHV,YUV, YC,COMPOSITION, etc | |
Related Products
Outdoor LED modules
Company Information
Our service
Pre-sale service:
1. Inquiries will be replied within 24 hours.
2. Market research and forecast for customer.
3. Provide unique and professional solutions based on customer's requirement.
4. Data sheet and samples offered.
5. Other requireed services such as special packing design, factory visiting and so on.
In-sale service:
1. Tracking producing procedures all the time.
2. Provide photos and videos as per customer's requirement during production.
3. Free spare parts provided.
After-sale service:
1. Complaint respond period not exceed 24 hours; maintenance guidance and problem solution supplied in 48 hours.
2. Warranty: 2years
3. Free technician training.
4. Full set of documents free of charge, which including installation guidance, software operation manual, easy maintenance manual and control system software CD and so on.
FAQ
