ACF-1 NSF certificated active carbon fiber for alkaline water ionizer
Product Description
Standard Model (Household Model)
Model
ACF-1
ACF-3
Q’ty of electrolysis plates
3 plates
5 plates
Electrolysis Plate Material
Platinum-titanium plate; manufactured by KOBE Steel, Japan
Voltage
AC110V / AC220V, 50/60HZ
Power Consumption
Max. 180W
Max. 230W
Inlet Water Pressure
0.9~5.0 kg/cm2
Electrolysis Method
Continuous electrolysis (built-in flow meter)
Water Flow Rate
Ideal water processing: 2 Liters/min. (based on inlet water pressure 1kgf/cm2) Water flow rate: 3 Liters/min. (based on inlet water pressure 2kgf/cm2)
Cleaning
10 second automatic cleansing after each alkaline water use * manual cleansing option if Alkaline water consumption is below 30 liters
Electrolysis Levels
4 Alkaline levels, 1 Pure level and 1 Acidic level
Filter Material
Activated carbon fiber (ACF), manufactured in USA
Filter Service Life
6,000 liters(depends on source water quality)
Safety Protection Device
Current protection & Alarm only if drinking Acidic water
Dimension & Weight
Approx.: H 310mm x W 202mm x D 125mm Weight: 4.1kg
pH Value
(based on source water quality)
5~10
4.5~11
O.R.P Value
(based on source water quality)
-650mv (Max.)
-850mv (Max.)
Feature
Active carbon fiber filter
Industry leading USA manufacturing technique complies with the highest drinking water standards
Higher absorption efficiency than coconut-shell granular carbon, is able to absorb very fine impurities, chemicals, such as chlorine, agriculture pesticides, etc.
Series Products
Company Information
Trade Show
work shop
Certification
Installation
FAQ
Q:What functions does water ionizer bring?
A:Through electrolysis, ionized water contains rich Alkaline Water-soluble minerals,such as Calcium,Magnesium, Potassium,Sodium and so on.The molecular clusters of Ionized water are broken down from 15 pieces to 6 pieces.
That makes water molecules easier for the human body to Metabolize.
Q:Is underground water suitable for ionization?
A: Generally the underground water is connected with rivers and streams all around.And the water is not tested or Treated by city water works.Heavy metals or chemical pollution is possible,if not probable,Therefore underground water is not adequate for water ionizers.
Q:What’s “good” about drinking Alkaline water?
A: It’s pure, no harmful imperities. It contains small and slightly Alkaline molecules.Small molecules feature high osmosis and high solution capacity. They are easily assimilated by the human body and help the Body to metabolize harmful elements.
