Custom high permeability soft toroidal ferrite core

\t
SIZE CODE (mm)
\t
A
\t
B
\t
C
\t
A2 T 31*8*19
\t
31.0±1.0
\t
8.0±0.5
\t
19.0±0.6
Parameter
\t
Electrical Requirements
\t
SIZE CODE (mm)
\t
A2 T 31*8*19
\t
at 25 MHz
\t
20 Ω MIN
\t
at 100 MHz
\t
66 Ω MIN
\t
TEST INSTRUMENTS
\t
HP 4191A
\t
LCR METER
\t
HP 4286
\t
WIRE
\t
0.65T.C.W*100m/m 1/2Ts
\t
TEMPERATURE
\t
15℃ to 35℃
\t
Test Data For Pre Production Samples
\t
MEAS.
 Item
\t
Ω
 AT 25MHz
\t
Ω
 AT 100MHz
\t
  A
 m/m
\t
B
 m/m
\t
C
 m/m
\t
Suggest
\t
20 Ω MIN
\t
66 Ω MIN
\t
31.0±1.0
\t
8.0±0.5
\t
19.0±0.6
\t
1
\t
29.03
\t
81.15
\t
30.98
\t
7.92
\t
18.82
\t
2
\t
29.54
\t
80.79
\t
30.95
\t
7.95
\t
18.95
\t
3
\t
29.52
\t
80.52
\t
31.04
\t
7.93
\t
18.93
\t
4
\t
29.07
\t
80.56
\t
30.98
\t
7.95
\t
18.89
\t
5
\t
30.12
\t
81.12
\t
30.98
\t
7.95
\t
18.90
\t
6
\t
28.46
\t
81.05
\t
31.01
\t
7.93
\t
18.96
\t
7
\t
29.52
\t
80.78
\t
31.03
\t
7.92
\t
19.02
\t
8
\t
30.12
\t
82.13
\t
30.95
\t
7.95
\t
18.97
\t
9
\t
29.42
\t
80.56
\t
30.97
\t
7.98
\t
19.03
\t
10
\t
29.76
\t
80.75
\t
31.02
\t
7.98
\t
18.99
\t
\t
\t
\t
\t
\t
\t
X-bar
\t
29.46
\t
80.94
\t
30.99
\t
7.95
\t
18.95
\t
R
\t
1.66
\t
1.61
\t
0.09
\t
0.06
\t
0.21
\t
The above test data for reference,Actual results may differ due to different production batches.
