cctv av matrix switcher 18x18 modular video matrix switcher support seamless EDID 4K dual power dual control backup
- Category: >>>
- Supplier: Kensence (shenzhen) Technology Development Co. Ltd.
Share on (60679601023):
Product Overview
Description
cctv av matrix switcher 18x18 modular video matrix switcher support seamless EDID 4K dual power dual control backup
Product Description
Product Introduction of av matrix
- Ø Kensence’s innovative S-Mix-E series Matrix Switcher supports Super definition of 4K/30fps resolution. It’s a high-performance, high bandwidth, flexible and reliable solution for 4K Super definition digital video display system.
- Ø This series of Matrix Switcher make it into fact that various forms of signal such as CVBS,YPbPr,VGA,HDMI,DVI,3GSDI+ AUDIO,3GSDI,HDBaseT and Fibel can switch arbitrarily. It applies self-researched K-OC image technology to make sure signal and signal can switch rapidly, without black field and jitter.
- Ø This kind of matrix ranges from 8*8,18*18,32*32 to 72*72 to meet different needs of different users.
Product Features of av matrix switcher
- Ø Supports arbitrary switch between multiple video signals ,Supports Seamless switch
- Ø Supports CVBS,YPbPr,VGA,HDMI,DVI, 3GSDI+AUDIO,HDBaseT,Fibel,RS232 and IR signal input
- Ø Supports CVBS,YPbPr,VGA,HDMI,DVI, 3GSDI+AUDIO,HDBaseT and Fibel signal output.
- Ø Every input channel supports Scaler adjustment.
- Ø Every output channel supports 16 kinds of common resolution fixed outputing.
- Ø Supports Deep Color 48/36/30/24-bit,YUV4:2:2/4:4:4
- Ø HDBaseT cards can extend common audio video signals up to 100 meters with twisted pair.
- Ø Fibel cards can extend common audio video signals up to 2 kilometers with single mode optical fiber.
- Ø Supports RS-232,remote control, panel control and TCP&IP control.
- Ø 7 inch high-definition, true color touch screen on front panel can display real-time status.
- Ø LCD display screen on front panel can display real-time status. (S-Mix-E88)
Product Specification of av matrix switcher box
Matrix mainframe specification:
Model | S-Mix-E88 | S-Mix-E1818 | S-Mix-E3232 | S-Mix-E7272 | ||
Interface | Input signals/Input cards | 8/4 | 18/9 | 32/16 | 72/36 | |
Output signals/ output cards | 8/4 | 18/9 | 32/16 | 72/36 | ||
Input modes | HDMI-4K-IN2,HSDA-IN2,3GSDI-IN2,HDBaseT-IN2,FIBER-IN2 | |||||
Output mode | HDMI-4K-OUT2,HSDA-OUT2,3GSDI-OUT2,HDBaseT-OUT2,FIBER-OUT2 | |||||
Bandwidth | 10.2Gbps | |||||
Control | RS232 control | Control protocol | RS232(Baud rate :115200, Data Bits:8, Stop Bits:1,no parity bit) | |||
Connector | 9 needles D-sub(DE9F) outlet 3=TX 2=RX 5=GND | |||||
TCP&IP control | Control protocol | TCP/IP | ||||
Connector | RJ45 joint 10/100Base-T Ethernet | |||||
Size | Width | 483mm | 483mm | 483mm | 483mm | |
Height | 2.5U/110mm | 6U/264mm | 11U/484mm | 25U/1100mm | ||
Depth | 370mm | 350mm | 370mm | 370mm | ||
Electrostatic protection | Human-body discharge pattern: ±8kV (Air-Gap Discharge) ±4kV (Contact Discharge) | |||||
Power | 12 V/3 A DC (US/EU Standard, CE/FCC Certified) | |||||
Input voltage | Power100VAC~260VAC,50/60 Hz, International adaptive power 23W (Maximum)/ 0.5w(Standby) | |||||
Operating Temperature | 0ºC~40ºC | |||||
Storage Temperature | −20ºC~60ºC | |||||
Product Pictures of HDMI cctv video matrix switcher
8x8 matrix :
18x18 matrix
32x32 matrix
