Low Cost 300Mbps Wireless N WiFi Router with MT7628KN Chipset

Share on (60679796907):


Price:RUB 525.86 - RUB 593.67

Quantity:


Product Overview

Description

Overview:


The Wireless Mini Router, supports 802.11 N wireless transmission standards, and is backward compatible with IEEE802.11 b/g standards. It supports data rate up to 300 Mbps. The Wireless Mini Router is Mainly used for providing free WIFI service in big area such as factory, community, street or etc. It supports WEP, WPS and WPA/WPA2 of personal and enterprise encryption standards.


Specification:
Supports far-distance transmission, 100 meters indoor, 300 meters outdoor (depends on the environments around)

• Supports remote/local Web management and TFTP upgrade

• Supports AP and Wifi Repeater

• Cable Internet Access, 802.1X, with fixed 5dBi Antenna

• Universally complies with IEEE 802.11n, IEEE 802.11g and IEEE 802.11b standards.

• Supports AP, Router, Client, Bridge and Repeater modes.

• Provides one 10/100Mbps Auto-Negotiation Ethernet WAN port.

• Provides four 10/100Mbps Auto-Negotiation Ethernet LAN port.

• WLAN 802.11n for wireless high-speed access up to 300Mbps, ideal for video streaming, online gaming and Internet calling.

• Easy Setup Assistant provides quick & hassle free installation.

• Supports SSID broadcast control.

• WMM and WMM-APSD supported.

• Supports 64/128/152-bit WEP, complies with 128 bit WPA(TKIP/AES), supports MIC, IV Expansion, Shared Key Authentication, IEEE 802.1X.

• User interface supports free WEB software updates.

• Mini and pocket design, ideal for home or travel use.


Hardware Features
Standards
IEEE 802.11n, IEEE 802.11g, IEEE 802.11b
Wireless Signal

Rates With

Automatic Fallback
11n: Up to 300Mbps (Dynamic)

11g: Up to 54Mbps (Dynamic)

11b: Up to 11Mbps (Dynamic)
Frequency Range
2.4-2.4835GHz
Wireless Transmit Power
<20dBm(EIRP)
Modulation Type
DBPSK,DQPSK,CCK, OFDM
Receiver Sensitivity
135M: -68dBm@10% PER

54M: -68dBm@10% PER

11M: -85dBm@8% PER
Wireless Security
64/128 bit WEPWPA/WPA2, WPA-PSK/WPA2-PSK

(TKIP/AES)
Interface
1* 10/100M LAN Ports

4* 10/100M WAN Ports
Antenna Type
Fixed 5dBi Antenna
Power supply
Input AC100~240V,

Output DC/12V/0.5A
Work Environments
Operating Temperature: 0°C~40°C (32°F~104°F)
Storage Temperature: -40°C~70°C (-40°F~158°F)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
