VR AR 3D Glasses 2K IPS LCD Screen Display 120Hz MIPI Dsi Interface High Contrast

Items

Specifications

Unit

Remarks

Screen size

73.406(2.89” type)Diagonal

mm

Active area

51.84(H)x51.84(V)

mm

Pixel format

1440(H)x1440(V)

Pixel

1 Pixel=R+G+B dots

-

Pixel pitch

0.012(H)x0.036(V)

mm

Pixel configuration

R,G,B vertical stripes

-

Display mode

Normally Black

-

LDC Driving method

DC Driving/Column

-

Liquid Crystal Mode

New Mode2

-

Number of colors

16,777,216

colors

24bits

Outline dimensions

54.24x59.02x1.365

mm

Note 3-1

Mass

7

g
