Hot sale Ti Sapphire Crystal for high power laser pointer

Product Overview

Description



Ti Sapphire (Titanium doped Sapphire, Al₂O₃ Ti³⁺) has a wide range of emission band from 660 to 1050 nm, which facilitates a variety of existing and potential applications, such as tunable continuous-wave lasers, mode-locked oscillators, chirp-pulse amplifiers, thin disk oscillators/amplifiers and lidars.Moreover, the absorption band of Ti Sapphire is centered at 490 nm, ranging from 400 to 650 nm, which makes it suitable for pump sources of many different lasers, for example, argon ion, frequency doubled Nd YAG (Nd YLF), and copper vapor lasers.Because of 3.2 μs fluorescence lifetime, Ti Sapphire crystals can be effectively pumped by flash lamps in high-power laser systems.

In order to obtain good quality of Ti Sapphire crystals, the Ti³⁺ doping concentration has to be kept fairly low (e.g. 0.15% or 0.25%). Therefore limited pump absorption usually enforces the use of a crystal length of several millimeters, which in combination with the small pump spot size (for high pump intensity) means that a rather high pump brightness is required.Fortunately, Sapphire has also an excellent thermal conductivity, alleviating thermal effects even for high laser power.

Features of diode laser pumped Titanium doped Sapphire Crystal

Ø  Large gain-bandwidth

Ø  Very large emission bandwidth

Ø  Excellent thermal conductivity

Ø  Short excited-state lifetime (3.2 μs)

Ø  High saturation power

Ø  Relatively high laser cross-sections

Ø  High damage threshold

Ø  Strong Kerr effect

Ø  Wide possible pump wavelengths

Applications of diode laser pumped Titanium doped Sapphire Crystal

Ø  Femtosecond pulse lasers

Ø  High repetition rate oscillators

Ø  Chirped-pulse laser amplifiers

Ø  Multi-pass amplifiers

Ø  Regenerative amplifiers

Ø  Wavelength tunable CW lasers

Ø  Pulsed X-ray generation

Ø  Thin disk oscillator

Ø  Petawatt laser systems

 Parameters of diode laser pumped Titanium doped Sapphire Crystal

Property	Value
Chemical formula	Ti3+ Al2O3
Crystal structure	hexagonal
Orientation	A-Axis within 5°,E-vector parallel to C-Axis
Mass density	3.98 g/cm3
Moh hardness	9
Young's modulus	335 GPa
Tensile strength	400 MPa
Melting point	2040 °C
Thermal conductivity	33 W / (m K)
Thermal expansion coefficient	≈ 5 × 10-6K-1
Thermal shock resistance parameter	790 W/m
Refractive index at 633 nm	1.76
Temperature dependence of refractive index	13 × 10-6K-1
Ti density for 0.1% at. doping	4.56 × 1019 cm-3
Concentrations	(0.05~0.35) wt%
End Configuration	Flat/Flat or Brewster/Brewster ends
Emission cross section at 790 nm (polarization parallel to the c axis)	41 × 10-20 cm2
Coatings	Standard coating is AR with R < 5.0% each face @532 nm and R < 0.5% each face, from 650 nm to 850 nm. Custom coatings supported.



Polishing Specification of diode laser pumped Titanium doped Sapphire Crystal

Property	Value
Orientation Tolerence	< 0.5°
Thickness/Diameter Tolerance	±0.05 mm
Surface Flatness	<λ/8@632 nm
Wavefront Distortion	<λ/4@632 nm
Surface Quality	10/5
Parallel	30 ″
Perpendicular	15 ′
Clear Aperture	>90%
Chammfer	<0.2×45°
Maximum dimensions	dia 150mm

Standard products of diode laser pumped Titanium doped Sapphire Crystal

Aperture dimension/mm	Length/mm	End surface	Coatings	FOM
6	5	Brewster Cut	-	>120
	10			>150
	15			>150
	20			>180
	5	Right-angle Cut	(R<1%)@532 nm + (R<0.3%)780-820 nm	>120
	10			>150
	15			>150
	20			>180
6x6	5	Brewster Cut	-	>120
	10			>150
	15			>150
	20			>180
	5	Right-angle Cut	(R<1%)@532 nm + (R<0.3%)780-820 nm	>120
	10			>150
	15			>150
	20			>180



Absorption Spectrum of diode laser pumped Titanium doped Sapphire Crystal









Q1: Can I have samples to test?

A: Yes,we are pleased to supply samples to test and check quality,mixed sample order is available.

Q2: Do you have any MOQ limited? A: Our MOQ: 1pcs Q3: What’s the lead time?

A: Sample :2-3 days.Mass production: 15-20 days.

Q4:How do you ship the goods and how long does it take?

A: We usually ship goods by UPS,FEDEX,TNT. It usually takes 3-5 days to arrive.

Q5: Do you offer guarantee for your products?

A: After test them if not pass test,you can return the goods at any time, we will re-offer you again and also bear shipping fee.

Q6: Do you accept OEM?

A: We have our own brand-metalaser. OEM is also acceptable.
